Lijian Zhao has uploaded this change for review. ( https://review.coreboot.org/c/coreboot/+/32834
Change subject: Documentation: Convert Intel to markdown ......................................................................
Documentation: Convert Intel to markdown
Convert all the left over html files to markdown.
Signed-off-by: Lijian Zhao lijian.zhao@intel.com Change-Id: I3975cc77fbbca397a071b3f412ca22b3c1516b0d --- D Documentation/Intel/Board/board.html A Documentation/Intel/Board/board.md D Documentation/Intel/Board/galileo.html A Documentation/Intel/Board/galileo.md D Documentation/Intel/SoC/quark.html A Documentation/Intel/SoC/quark.md D Documentation/Intel/SoC/soc.html A Documentation/Intel/SoC/soc.md D Documentation/Intel/development.html A Documentation/Intel/development.md D Documentation/Intel/fsp1_1.html A Documentation/Intel/fsp1_1.md D Documentation/Intel/index.html A Documentation/Intel/index.md 14 files changed, 1,440 insertions(+), 1,887 deletions(-)
git pull ssh://review.coreboot.org:29418/coreboot refs/changes/34/32834/1
diff --git a/Documentation/Intel/Board/board.html b/Documentation/Intel/Board/board.html deleted file mode 100644 index 4ba51df..0000000 --- a/Documentation/Intel/Board/board.html +++ /dev/null @@ -1,239 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>Board</title> - </head> - <body> - -<h1>x86 Board Development</h1> -<p> - Board development requires System-on-a-Chip (SoC) support. - The combined steps are listed - <a target="_blank" href="../development.html">here</a>. - The development steps for the board are listed below: -</p> -<ol> - <li><a href="#RequiredFiles">Required Files</a></li> - <li>Enable <a href="#SerialOutput">Serial Output</a></li> - <li>Load the <a href="#SpdData">Memory Timing Data</a></li> - <li><a href="#DisablePciDevices">Disable</a> the PCI devices</li> - <li><a href="#AcpiTables">ACPI Tables</a></li> -</ol> - - -<hr> -<h2><a name="RequiredFiles">Required Files</a></h2> -<p> - Create the board directory as src/mainboard/<Vendor>/<Board>. -</p> - -<p> - The following files are required to build a new board: -</p> -<ol> - <li>Kconfig.name - Defines the Kconfig value for the board</li> - <li>Kconfig - <ol type="A"> - <li>Selects the SoC for the board and specifies the SPI flash size - <ol type="I"> - <li>BOARD_ROMSIZE_KB_<Size></li> - <li>SOC_<Vendor>_<Chip Family></li> - </ol> - </li> - <li>Declare the Kconfig values for: - <ol type="I"> - <li>MAINBOARD_DIR</li> - <li>MAINBOARD_PART_NUMBER</li> - <li>MAINBOARD_VENDOR</li> - </ol> - </li> - </ol> - </li> - <li>devicetree.cb - Enable root bridge and serial port - <ol type="A"> - <li>The first line must be "chip soc/Intel/<soc family>"; - this path is used by the generated static.c to include the chip.h - header file - </li> - </ol> - </li> - <li>romstage.c - <ol type="A"> - <li>Add routine mainboard_romstage_entry which calls romstage_common</li> - </ol> - </li> - <li>Configure coreboot build: - <ol type="A"> - <li>Set LOCALVERSION</li> - <li>Select vendor for the board</li> - <li>Select the board</li> - <li>CBFS_SIZE = 0x00100000</li> - <li>Set the CPU_MICROCODE_CBFS_LEN</li> - <li>Set the CPU_MICROCODE_CBFS_LOC</li> - <li>Set the FSP_IMAGE_ID_STRING</li> - <li>Set the FSP_LOC</li> - <li>No payload</li> - <li>Choose the default value for all other options</li> - </ol> - </li> -</ol> - - -<hr> -<h2><a name="SerialOutput">Enable Serial Output</a></h2> -<p> - Use the following steps to enable serial output: -</p> -<ol> - <li>Implement the car_mainboard_pre_console_init routine in the com_init.c - file: - <ol type="A"> - <li>Power on and enable the UART controller</li> - <li>Connect the UART receive and transmit data lines to the - appropriate SoC pins - </li> - </ol> - </li> - <li>Add Makefile.inc - <ol type="A"> - <li>Add com_init.c to romstage</li> - </ol> - </li> -</ol> - - -<hr> -<h2><a name="SpdData">Memory Timing Data</a></h2> -<p> - Memory timing data is located in the flash. This data is in the format of - <a target="_blank" href="https://en.wikipedia.org/wiki/Serial_presence_detect">serial presence detect</a> - (SPD) data. - Use the following steps to load the SPD data: -</p> -<ol> - <li>Edit Kconfig to add the DISPLAY_SPD_DATA" value which enables the - display of the SPD data being passed to MemoryInit - </li> - <li>Create an "spd" subdirectory</li> - <li>Create an spd/spd.c file for the SPD implementation - <ol type="A"> - <li>Implement the mainboard_fill_spd_data routine - <ol type="i"> - <li>Read the SPD data either from the spd.bin file or using I2C or SMBUS</li> - <li>Fill in the pei_data structure with SPD data for each of the DIMMs</li> - <li>Set the DIMM channel configuration</li> - </ol> - </li> - </ol> - </li> - <li>Add an .spd.hex file containing the memory timing data to the spd subdirectory</li> - <li>Create spd/Makefile.inc - <ol type="A"> - <li>Add spd.c to romstage</li> - <li>Add the .spd.hex file to SPD_SOURCES</li> - </ol> - </li> - <li>Edit Makefile.inc to add the spd subdirectory</li> - <li>Edit romstage.c - <ol type="A"> - <li>Call mainboard_fill_spd_data</li> - <li>Add mainboard_memory_init_params to copy the SPD and DRAM - configuration data from the pei_data structure into the UPDs - for MemoryInit - </li> - </ol> - </li> - <li>Edit devicetree.cb - <ol type="A"> - <li>Include the UPD parameters for MemoryInit except for: - <ul> - <li>Address of SPD data</li> - <li>DRAM configuration set above</li> - </ul> - </li> - </ol> - </li> - <li>A working FSP - <a target="_blank" href="../fsp1_1.html#MemoryInit">MemoryInit</a> - routine is required to complete debugging</li> - <li>Debug the result until port 0x80 outputs - <ol type="A"> - <li>0x34: - - Just after entering - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l67">raminit</a> - </li> - <li>0x36: - - Just before displaying the - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l106">UPD parameters</a> - for FSP MemoryInit - </li> - <li>0x92: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l219">POST_FSP_MEMORY_INIT</a> - - Just before calling FSP - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l125">MemoryInit</a> - </li> - <li>0x37: - - Just after returning from FSP - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l127">MemoryInit</a> - </li> - </ol> - </li> - <li>Continue debugging with CONFIG_DISPLAY_HOBS enabled until TempRamExit is called</li> -</ol> - - - -<hr> -<h2><a name="DisablePciDevices">Disable PCI Devices</a></h2> -<p> - Ramstage's BS_DEV_ENUMERATE state displays the PCI vendor and device IDs for all - of the devices in the system. Edit the devicetree.cb file: -</p> -<ol> - <li>Edit the devicetree.cb file: - <ol type="A"> - <li>Add an entry for a PCI device.function and turn it off. The entry - should look similar to: -<pre><code>device pci 14.0 off end</code></pre> - </li> - <li>Turn on the devices for: - <ul> - <li>Memory Controller</li> - <li>Debug serial device</li> - </ul> - </li> - </ol> - </li> - <li>Debug until the BS_DEV_ENUMERATE state shows the proper state for all of the devices</li> -</ol> - - - -<hr> -<h2><a name="AcpiTables">ACPI Tables</a></h2> -<ol> - <li>Edit Kconfig - <ol type="A"> - <li>Add "select HAVE_ACPI_TABLES"</li> - </ol> - </li> - <li>Add the acpi_tables.c module: - <ol type="A"> - <li>Include soc/acpi.h</li> - <li>Add the acpi_create_fadt routine - <ol type="I"> - <li>fill in the ACPI header</li> - <li>Call the acpi_fill_in_fadt routine</li> - </ol> - </li> - </ol> - </li> - <li>Add the dsdt.asl module: - </li> -</ol> - - - -<hr> -<p>Modified: 20 February 2016</p> - </body> -</html> diff --git a/Documentation/Intel/Board/board.md b/Documentation/Intel/Board/board.md new file mode 100644 index 0000000..9f55252 --- /dev/null +++ b/Documentation/Intel/Board/board.md @@ -0,0 +1,156 @@ +x86 Board Development +===================== + +Board development requires System-on-a-Chip (SoC) support. The combined +steps are listed [here](../development.html). The development steps for +the board are listed below: + +1. [Required Files](#RequiredFiles) +2. Enable [Serial Output](#SerialOutput) +3. Load the [Memory Timing Data](#SpdData) +4. [Disable](#DisablePciDevices) the PCI devices +5. [ACPI Tables](#AcpiTables) + +------------------------------------------------------------------------ + +[Required Files]{#RequiredFiles} +-------------------------------- + +Create the board directory as +src/mainboard/<Vendor>/<Board>. + +The following files are required to build a new board: + +1. Kconfig.name - Defines the Kconfig value for the board +2. Kconfig + A. Selects the SoC for the board and specifies the SPI flash size + I. BOARD_ROMSIZE_KB_<Size> + II. SOC_<Vendor>_<Chip Family> + B. Declare the Kconfig values for: + I. MAINBOARD_DIR + II. MAINBOARD_PART_NUMBER + III. MAINBOARD_VENDOR +3. devicetree.cb - Enable root bridge and serial port + A. The first line must be "chip soc/Intel/<soc family>"; this + path is used by the generated static.c to include the chip.h + header file +4. romstage.c + A. Add routine mainboard_romstage_entry which calls + romstage_common +5. Configure coreboot build: + A. Set LOCALVERSION + B. Select vendor for the board + C. Select the board + D. CBFS_SIZE = 0x00100000 + E. Set the CPU_MICROCODE_CBFS_LEN + F. Set the CPU_MICROCODE_CBFS_LOC + G. Set the FSP_IMAGE_ID_STRING + H. Set the FSP_LOC + I. No payload + J. Choose the default value for all other options + +------------------------------------------------------------------------ + +[Enable Serial Output]{#SerialOutput} +------------------------------------- + +Use the following steps to enable serial output: + +1. Implement the car_mainboard_pre_console_init routine in the + com_init.c file: + A. Power on and enable the UART controller + B. Connect the UART receive and transmit data lines to the + appropriate SoC pins +2. Add Makefile.inc + A. Add com_init.c to romstage + +------------------------------------------------------------------------ + +[Memory Timing Data]{#SpdData} +------------------------------ + +Memory timing data is located in the flash. This data is in the format +of [serial presence +detect](https://en.wikipedia.org/wiki/Serial_presence_detect) (SPD) +data. Use the following steps to load the SPD data: + +1. Edit Kconfig to add the DISPLAY_SPD_DATA" value which enables the + display of the SPD data being passed to MemoryInit +2. Create an "spd" subdirectory +3. Create an spd/spd.c file for the SPD implementation + A. Implement the mainboard_fill_spd_data routine + i. Read the SPD data either from the spd.bin file or using I2C + or SMBUS + ii. Fill in the pei_data structure with SPD data for each of + the DIMMs + iii. Set the DIMM channel configuration +4. Add an .spd.hex file containing the memory timing data to the spd + subdirectory +5. Create spd/Makefile.inc + A. Add spd.c to romstage + B. Add the .spd.hex file to SPD_SOURCES +6. Edit Makefile.inc to add the spd subdirectory +7. Edit romstage.c + A. Call mainboard_fill_spd_data + B. Add mainboard_memory_init_params to copy the SPD and DRAM + configuration data from the pei_data structure into the UPDs + for MemoryInit +8. Edit devicetree.cb + A. Include the UPD parameters for MemoryInit except for: + - Address of SPD data + - DRAM configuration set above +9. A working FSP [MemoryInit](../fsp1_1.html#MemoryInit) routine is + required to complete debugging +10. Debug the result until port 0x80 outputs + A. 0x34: - Just after entering + [raminit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. 0x36: - Just before displaying the [UPD + parameters](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + for FSP MemoryInit + C. 0x92: + [POST_FSP_MEMORY_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Just before calling FSP + [MemoryInit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + D. 0x37: - Just after returning from FSP + [MemoryInit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) +11. Continue debugging with CONFIG_DISPLAY_HOBS enabled until + TempRamExit is called + +------------------------------------------------------------------------ + +[Disable PCI Devices]{#DisablePciDevices} +----------------------------------------- + +Ramstage's BS_DEV_ENUMERATE state displays the PCI vendor and device +IDs for all of the devices in the system. Edit the devicetree.cb file: + +1. Edit the devicetree.cb file: + A. Add an entry for a PCI device.function and turn it off. The + entry should look similar to: + + device pci 14.0 off end + + B. Turn on the devices for: + - Memory Controller + - Debug serial device + +2. Debug until the BS_DEV_ENUMERATE state shows the proper state for + all of the devices + +------------------------------------------------------------------------ + +[ACPI Tables]{#AcpiTables} +-------------------------- + +1. Edit Kconfig + A. Add "select HAVE_ACPI_TABLES" +2. Add the acpi_tables.c module: + A. Include soc/acpi.h + B. Add the acpi_create_fadt routine + I. fill in the ACPI header + II. Call the acpi_fill_in_fadt routine +3. Add the dsdt.asl module: + +------------------------------------------------------------------------ + +Modified: 20 February 2016 diff --git a/Documentation/Intel/Board/galileo.html b/Documentation/Intel/Board/galileo.html deleted file mode 100644 index f7edf6e..0000000 --- a/Documentation/Intel/Board/galileo.html +++ /dev/null @@ -1,113 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>Galileo</title> - </head> - <body> - -<h1>Intel® Galileo Development Board</h1> -<table> - <tr> - <td><a target="_blank" href="http://www.mouser.com/images/microsites/Intel_Galileo2_lrg.jpg"><img alt="Galileo Gen 2" src="http://www.mouser.com/images/microsites/Intel_Galileo2_lrg.jpg" width=500></a></td> - <td> - The Intel® Galileo Gen 2 mainboard code was developed along with the Intel® - <a target="_blank" href="../SoC/quark.html">Quark™</a> SoC: - <ul> - <li><a target="_blank" href="../development.html">Overall</a> development</li> - <li><a target="_blank" href="../SoC/soc.html">SoC</a> support</li> - <li><a target="_blank" href="../fsp1_1.html">FSP 1.1</a> integration</li> - <li><a target="_blank" href="board.html">Board</a> support</li> - </ul> - </td> - </tr> -</table> - - - -<hr> -<h2>Galileo Board Documentation</h2> -<ul> - <li>Common Components - <ul> - <li>A/D: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/adc108s102.pdf">ADC108S102</a></li> - <li>Analog Switch: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/ts5a23159.pdf">TS5A23159</a></li> - <li>Ethernet (10/100 MB/S): Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/dp83848-ep.pdf">DP83848</a></li> - <li>Load Switch: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/tps22920.pdf">TPS22920x</a></li> - <li>Memory (256 MiB): Micron <a target="_blank" href="https://www.micron.com/~/media/Documents/Products/Data%20Sheet/DRAM/DDR3/1Gb_1_35V_DDR3L.pdf">MT41K128M8</a></li> - <li>SoC: Intel® Quark™ <a target="_blank" href="../SoC/quark.html">X-1000</a></li> - <li>Serial EEPROM (1 KiB): ON Semiconductor® <a target="_blank" href="http://www.onsemi.com/pub_link/Collateral/CAT24C01-D.PDF">CAT24C08</a></li> - <li>SPI Flash (8 MiB): Winbond™ <a target="_blank" href="http://www.winbond-usa.com/resource-files/w25q64fv_revl1_100713.pdf">W25Q64FV</a></li> - <li>Step Down Converter: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/slvsag7c/slvsag7c.pdf">TPS62130</a></li> - <li>Step Down Converter: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ug/slvu570/slvu570.pdf">TPS652510</a></li> - <li>Termination Regulator: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/tps51200.pdf">TPS51200</a></li> - </ul> - </li> - <li>Make a bootable <a target="_blank" href="https://software.intel.com/en-us/get-started-galileo-linux-step1">micro SD card</a></li> -</ul> - -<h3>Galileo Gen 2 Board Documentation</h3> -<ul> - <li><a target="_blank" href="http://files.linuxgizmos.com/intel_galileo_gen2_blockdiagram.jpg">Block Diagram</a></li> - <li><a target="_blank" href="https://software.intel.com/en-us/iot/library/galileo-getting-started">Getting Started</a></li> - <li><a target="_blank" href="http://www.intel.com/content/www/us/en/embedded/products/galileo/galileo-overview.html">Overview</a></li> - <li><a target="_blank" href="http://files.linuxgizmos.com/intel_galileo_gen2_ports.jpg">Port Diagram</a></li> - <li><a target="_blank" href="http://download.intel.com/support/galileo/sb/intelgalileogen2prodbrief_330736_003.pdf">Product Brief</a></li> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/guides/galileo-g2-schematic.pdf">Schematic</a></li> - <li><a target="_blank" href="http://download.intel.com/support/galileo/sb/galileo_boarduserguide_330237_001.pdf">User Guide</a></li> - <li>Components - <ul> - <li>A/D: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/adc108s102.pdf">ADC108S102</a></li> - <li>I2C 16-channel, 12-bit PWM: NXP Semiconductors <a target="_blank" href="http://cache.nxp.com/documents/data_sheet/PCA9685.pdf">PCA9685</a></li> - <li>I2C I/O Ports: NXP Semiconductors <a target="_blank" href="http://www.nxp.com/documents/data_sheet/PCAL9535A.pdf">PCAL9535A</a></li> - <li>Octal Buffer/Driver: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/sn74lv541at.pdf">SN74LV541AT</a></li> - <li>Quadruple Bus Buffer: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/sn74lv125a.pdf">SN74LV125A</a></li> - <li>Quadruple Bus Buffer with 3-State Outputs: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/sn74lvc126a.pdf">SN74LVC126A</a></li> - <li>Serial EEPROM (1 KiB): ON Semiconductor® <a target="_blank" href="http://www.onsemi.com/pub_link/Collateral/CAT24C01-D.PDF">CAT24C08</a></li> - <li>Single 2-input multiplexer: NXP Semiconductors <a target="_blank" href="http://www.nxp.com/documents/data_sheet/74LVC1G157.pdf">74LVC1G157</a></li> - <li>Step Down Converter: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/slvsag7c/slvsag7c.pdf">TPS62130</a></li> - </ul> - </li> -</ul> - -<h3>Galileo Gen 1 Board Documentation</h3> -<ul> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/datasheets/galileo-g1-datasheet.pdf">Datasheet</a></li> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/guides/galileo-g1-schematic.pdf">Schematic</a></li> - <li>Components - <ul> - <li>A/D: Analog Devices <a target="_blank" href="http://www.analog.com/media/en/technical-documentation/data-sheets/AD7298-1.pdf">AD7298</a></li> - <li>Analog Switch, 2 channel: Texas Instruments <a target="_blank" href="http://www.ti.com.cn/cn/lit/ds/symlink/ts5a23159.pdf">TS5A23159</a></li> - <li>EEPROM & GPIO: Cypress <a target="_blank" href="http://www.cypress.com/file/37971/download">CY8C9540A</a></li> - <li>Power Distribution Switch: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/tps2044b.pdf">TPS2051BDBVR</a></li> - <li>RS232 Converter: Texas Instruments <a target="_blank" href="http://www.ti.com/lit/ds/symlink/max3232.pdf">MAX3232</a></li> - <li>Voltage-Level Translator: Texas Instruments<a target="_blank" href="http://www.ti.com/lit/ds/symlink/txs0108e.pdf">TXS0108E</a></li> - </ul> - </li> -</ul> - - - -<hr> -<h2>Debug Tools</h2> -<ul> - <li>Flash Programmer: - <ul> - <li>Dediprog <a target="_blank" href="http://www.dediprog.com/pd/spi-flash-solution/SF100">SF100</a> ISP IC Programmer</li> - </ul> - </li> - <li>JTAG Connector: <a target="_blank" href="https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=Olimex+ARM-JTAG-20-10">Olimex ARM-JTAG-20-10</a></li> - <li>JTAG Debugger: - <ul> - <li>Olimex LTD <a target="_blank" href="https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=Olimex+ARM-USB-OCD-H">ARM-USB-OCD-H</a></li> - <li>Tincan Tools <a target="_blank" href="https://www.tincantools.com/wiki/Flyswatter2">Flyswatter2</a></li> - </ul> - </li> - <li><a target="_blank" href="http://download.intel.com/support/processors/quark/sb/sourcedebugusingopenocd_quark_appnote_330015_003.pdf">Hardware Setup and Software Installation</a></li> - <li>USB Serial cable: FTDI <a target="_blank" href="https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&ie=UTF-8#q=FTDI+TTL-232R-3V3">TTL-232R-3V3</a></li> -</ul> - - -<hr> -<p>Modified: 29 February 2016</p> - </body> -</html> diff --git a/Documentation/Intel/Board/galileo.md b/Documentation/Intel/Board/galileo.md new file mode 100644 index 0000000..7cee25c --- /dev/null +++ b/Documentation/Intel/Board/galileo.md @@ -0,0 +1,124 @@ +Intel® Galileo Development Board +================================ + ++-----------------------------------+-----------------------------------+ +| [ | along with the Intel® | +| {width="500"}](http://www.mouser. | [Quark™](../SoC/quark.html) SoC: | +| com/images/microsites/Intel_Galil | - [Overall](../development.html | +| eo2_lrg.jpg) | ) | +| | development | +| | - [SoC](../SoC/soc.html) | +| | support | +| | - [FSP 1.1](../fsp1_1.html) | +| | integration | +| | - [Board](board.html) support | ++-----------------------------------+-----------------------------------+ + +------------------------------------------------------------------------ + +Galileo Board Documentation +--------------------------- + +- Common Components + - A/D: Texas Instruments + [ADC108S102](http://www.ti.com/lit/ds/symlink/adc108s102.pdf) + - Analog Switch: Texas Instruments + [TS5A23159](http://www.ti.com/lit/ds/symlink/ts5a23159.pdf) + - Ethernet (10/100 MB/S): Texas Instruments + [DP83848](http://www.ti.com/lit/ds/symlink/dp83848-ep.pdf) + - Load Switch: Texas Instruments + [TPS22920x](http://www.ti.com/lit/ds/symlink/tps22920.pdf) + - Memory (256 MiB): Micron + [MT41K128M8](https://www.micron.com/~/media/Documents/Products/Data%20Sheet/DRAM/DDR3/1Gb...) + - SoC: Intel® Quark™ [X-1000](../SoC/quark.html) + - Serial EEPROM (1 KiB): ON Semiconductor® + [CAT24C08](http://www.onsemi.com/pub_link/Collateral/CAT24C01-D.PDF) + - SPI Flash (8 MiB): Winbond™ + [W25Q64FV](http://www.winbond-usa.com/resource-files/w25q64fv_revl1_100713.pdf) + - Step Down Converter: Texas Instruments + [TPS62130](http://www.ti.com/lit/ds/slvsag7c/slvsag7c.pdf) + - Step Down Converter: Texas Instruments + [TPS652510](http://www.ti.com/lit/ug/slvu570/slvu570.pdf) + - Termination Regulator: Texas Instruments + [TPS51200](http://www.ti.com/lit/ds/symlink/tps51200.pdf) +- Make a bootable [micro SD + card](https://software.intel.com/en-us/get-started-galileo-linux-step1) + +### Galileo Gen 2 Board Documentation + +- [Block + Diagram](http://files.linuxgizmos.com/intel_galileo_gen2_blockdiagram.jpg) +- [Getting + Started](https://software.intel.com/en-us/iot/library/galileo-getting-started) +- [Overview](http://www.intel.com/content/www/us/en/embedded/products/galileo/galileo-ove...) +- [Port + Diagram](http://files.linuxgizmos.com/intel_galileo_gen2_ports.jpg) +- [Product + Brief](http://download.intel.com/support/galileo/sb/intelgalileogen2prodbrief_33073...) +- [Schematic](http://www.intel.com/content/dam/www/public/us/en/documents/guides/galileo-g...) +- [User + Guide](http://download.intel.com/support/galileo/sb/galileo_boarduserguide_330237_0...) +- Components + - A/D: Texas Instruments + [ADC108S102](http://www.ti.com/lit/ds/symlink/adc108s102.pdf) + - I2C 16-channel, 12-bit PWM: NXP Semiconductors + [PCA9685](http://cache.nxp.com/documents/data_sheet/PCA9685.pdf) + - I2C I/O Ports: NXP Semiconductors + [PCAL9535A](http://www.nxp.com/documents/data_sheet/PCAL9535A.pdf) + - Octal Buffer/Driver: Texas Instruments + [SN74LV541AT](http://www.ti.com/lit/ds/symlink/sn74lv541at.pdf) + - Quadruple Bus Buffer: Texas Instruments + [SN74LV125A](http://www.ti.com/lit/ds/symlink/sn74lv125a.pdf) + - Quadruple Bus Buffer with 3-State Outputs: Texas Instruments + [SN74LVC126A](http://www.ti.com/lit/ds/symlink/sn74lvc126a.pdf) + - Serial EEPROM (1 KiB): ON Semiconductor® + [CAT24C08](http://www.onsemi.com/pub_link/Collateral/CAT24C01-D.PDF) + - Single 2-input multiplexer: NXP Semiconductors + [74LVC1G157](http://www.nxp.com/documents/data_sheet/74LVC1G157.pdf) + - Step Down Converter: Texas Instruments + [TPS62130](http://www.ti.com/lit/ds/slvsag7c/slvsag7c.pdf) + +### Galileo Gen 1 Board Documentation + +- [Datasheet](http://www.intel.com/content/dam/www/public/us/en/documents/datasheets/galil...) +- [Schematic](http://www.intel.com/content/dam/www/public/us/en/documents/guides/galileo-g...) +- Components + - A/D: Analog Devices + [AD7298](http://www.analog.com/media/en/technical-documentation/data-sheets/AD7298-1....) + - Analog Switch, 2 channel: Texas Instruments + [TS5A23159](http://www.ti.com.cn/cn/lit/ds/symlink/ts5a23159.pdf) + - EEPROM & GPIO: Cypress + [CY8C9540A](http://www.cypress.com/file/37971/download) + - Power Distribution Switch: Texas Instruments + [TPS2051BDBVR](http://www.ti.com/lit/ds/symlink/tps2044b.pdf) + - RS232 Converter: Texas Instruments + [MAX3232](http://www.ti.com/lit/ds/symlink/max3232.pdf) + - Voltage-Level Translator: Texas + Instruments[TXS0108E](http://www.ti.com/lit/ds/symlink/txs0108e.pdf) + +------------------------------------------------------------------------ + +Debug Tools +----------- + +- Flash Programmer: + - Dediprog + [SF100](http://www.dediprog.com/pd/spi-flash-solution/SF100) ISP + IC Programmer +- JTAG Connector: [Olimex + ARM-JTAG-20-10](https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&am...) +- JTAG Debugger: + - Olimex LTD + [ARM-USB-OCD-H](https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&am...) + - Tincan Tools + [Flyswatter2](https://www.tincantools.com/wiki/Flyswatter2) +- [Hardware Setup and Software + Installation](http://download.intel.com/support/processors/quark/sb/sourcedebugusingopenoc...) +- USB Serial cable: FTDI + [TTL-232R-3V3](https://www.google.com/webhp?sourceid=chrome-instant&ion=1&espv=2&am...) + +------------------------------------------------------------------------ + +Modified: 29 February 2016 diff --git a/Documentation/Intel/SoC/quark.html b/Documentation/Intel/SoC/quark.html deleted file mode 100644 index c3eead2..0000000 --- a/Documentation/Intel/SoC/quark.html +++ /dev/null @@ -1,220 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>Quark™ SoC</title> - </head> - <body> - -<h1>Intel® Quark™ SoC</h1> -<table> - <tr> - <td><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/images/embedded/16x9/edc-quark-block-diagram-16x9.png"><img alt="Quark Block Diagram" src="http://www.intel.com/content/dam/www/public/us/en/images/embedded/16x9/edc-quark-block-diagram-16x9.png" width=500></a></td> - <td> - The Quark™ SoC code was developed using the - <a target="_blank" href="../Board/galileo.html">Galileo Gen 2</a> - board: - <ul> - <li><a target="_blank" href="../development.html">Overall</a> development</li> - <li><a target="_blank" href="soc.html">SoC</a> support</li> - <li><a target="_blank" href="../fsp1_1.html">FSP 1.1</a> integration</li> - <li><a target="_blank" href="../Board/board.html">Board</a> support</li> - <li><a target="_blank" href="#QuarkFsp">Quark™ FSP</a></li> - <li><a target="_blank" href="#CorebootPayloadPkg">CorebootPayloadPkg</a></li> - </ul> - </td> - </tr> -</table> - - - -<hr> -<h2>Quark™ Documentation</h2> -<ul> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/images/embedded/16x9/edc-quark-block-diagram-16x9.png">Block Diagram</a></li> - <li><a target="_blank" href="http://www.intel.com/content/www/us/en/embedded/products/quark/specifications.html">Specifications</a>: - <ul> - <li><a target="_blank" href="http://ark.intel.com/products/79084/Intel-Quark-SoC-X1000-16K-Cache-400-MHz">X1000</a> - - <a target="_blank" href="http://www.intel.com/content/www/us/en/search.html?keyword=X1000">Documentation</a>: - <ul> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/datasheets/quark-x1000-datasheet.pdf">Datasheet</a></li> - <li><a target="_blank" href="http://www.intel.com/content/dam/support/us/en/documents/processors/quark/sb/intelquarkcore_devman_001.pdf">Developer's Manual</a></li> - <li><a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/intel-quark-product-brief-v3.pdf">Product Brief</a></li> - </ul> - </li> - </ul> - </li> - <li><a target="_blank" href="../index.html#Documentation">More documentation</a></li> -</ul> - - - -<hr> -<h2><a name="CorebootPayloadPkg">Quark™ EDK2 CorebootPayloadPkg</a></h2> -<p> -Build Instructions: -</p> -<ol> - <li>Set up <a href="#BuildEnvironment">build environment</a></li> - <li>Linux (assumes GCC48): -<pre><code>build -p CorebootPayloadPkg/CorebootPayloadPkgIa32.dsc -a IA32 \ - -t GCC48 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 \ - -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -DSHELL_TYPE=BUILD_SHELL \ - -DMAX_LOGICAL_PROCESSORS=1 -ls Build/CorebootPayloadPkgIA32/DEBUG_GCC48/FV/UEFIPAYLOAD.fd -</code></pre> - </li> - <li>Windows (assumes Visual Studio 2015): -<pre><code>build -p CorebootPayloadPkg\CorebootPayloadPkgIa32.dsc -a IA32 -t VS2015x86 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -DSHELL_TYPE=BUILD_SHELL -DMAX_LOGICAL_PROCESSORS=1 -dir Build\CorebootPayloadPkgIA32\DEBUG_VS2015x86\FV\UEFIPAYLOAD.fd -</code></pre> - </li> - <li>In the .config for coreboot, set the following Kconfig values: - <ul> - <li>CONFIG_PAYLOAD_ELF=y</li> - <li>CONFIG_PAYLOAD_FILE="path to UEFIPAYLOAD.fd"</li> - </ul> - </li> - <li>Build coreboot</li> - <li>Copy the image build/coreboot.rom into flash</li> -</ol> - - - -<hr> -<h2><a name="BuildEnvironment">Quark™ EDK2 Build Environment</a></h2> -<p> - Use the following steps to setup a build environment: -</p> -<ol> - <li>Get the EDK2 sources: - <ol type="A"> - <li>EDK2: git clone <a target="_blank" href="https://github.com/tianocore/edk2.git">https://github.com/tianocore/edk2.git</a></li> - <li>EDK2-non-osi: git clone <a target="_blank" href="https://github.com/tianocore/edk2-non-osi.git">https://github.com/tianocore/edk2-non-osi.git</a></li> - <li>Win32 BaseTools: git clone <a target="_blank" href="https://github.com/tianocore/edk2-BaseTools-win32.git">https://github.com/tianocore/edk2-BaseTools-win32.git</a></li> - </ol> - </li> - <li>Set up a build window: - <ul> - <li>Linux: -<pre><code>export WORKSPACE=$PWD -export PACKAGES_PATH="$PWD/edk2:$PWD/edk2-non-osi" -cd edk2 -export WORKSPACE=$PWD -. edksetup.sh -</code></pre> - </li> - <li>Windows: -<pre><code>set WORKSPACE=%CD% -set PACKAGES_PATH=%WORKSPACE%\edk2;%WORKSPACE%\edk2-non-osi -set EDK_TOOLS_BIN=%WORKSPACE%\edk2-BaseTools-win32 -cd edk2 -edksetup.bat -</code></pre> - </li> - </ul> - </li> -</ol> - - - -<hr> -<h2><a name="QuarkFsp">Quark™ FSP</a></h2> -<p> -Getting the Quark FSP source: -</p> -<ol> - <li>Set up an EDK-II <a href="#BuildEnvironment">Build Environment</a></li> - <li>cd edk2</li> - <li>mkdir QuarkFspPkg</li> - <li>cd QuarkFspPkg</li> - <li>Use git to clone <a target="_blank" href="https://review.gerrithub.io/#/admin/projects/LeeLeahy/quarkfsp">QuarkFspPkg</a> into the QuarkFpsPkg directory (.)</li> -</ol> - -<h3>Building QuarkFspPkg</h3> -<p> -There are two versions of FSP: FSP 1.1 and FSP 2.0. There are also two -different implementations of FSP, one using subroutines without SEC and -PEI core and the original implementation which relies on SEC and PEI core. -Finally there are two different build x86 types release (r32) and debug (d32). -</p> -<p>Note that the subroutine implementations are a <b>work in progress</b>.</p> -<p> -Build commands shown building debug FSP: -</p> -<ul> - <li>Linux: - <ul> - <li>QuarkFspPkg/BuildFsp1_1.sh -d32</li> - <li>QuarkFspPkg/BuildFsp1_1Pei.sh -d32</li> - <li>QuarkFspPkg/BuildFsp2_0.sh -d32</li> - <li>QuarkFspPkg/BuildFsp2_0Pei.sh -d32</li> - </ul> - <li>Windows: - <ul> - <li>QuarkFspPkg/BuildFsp1_1.bat -d32</li> - <li>Windows: QuarkFspPkg/BuildFsp2_0.bat -d32</li> - </ul> - </li> -</ul> - -<h3>Copying FSP files into coreboot Source Tree</h3> -<p> -There are some helper scripts to copy the FSP output into the coreboot -source tree. The parameters to these scripts are: -</p> -<ol> - <li>EDK2 tree root</li> - <li>coreboot tree root</li> - <li>Build type: DEBUG or RELEASE</li> -</ol> -<p> -Script files: -</p> -<ul> - <li>Linux: - <ul> - <li>QuarkFspPkg/coreboot_fsp1_1.sh</li> - <li>QuarkFspPkg/coreboot_fsp1_1Pei.sh</li> - <li>QuarkFspPkg/coreboot_fsp2_0.sh</li> - <li>QuarkFspPkg/coreboot_fsp2_0Pei.sh</li> - </ul> -</ul> - - -<hr> -<h2>Quark™ EDK2 BIOS</h2> -<p> -Build Instructions: -</p> -<ol> - <li>Set up <a href="#BuildEnvironment">build environment</a></li> - <li>Build the image: - <ul> - <li>Linux: -<pre><code>build -p QuarkPlatformPkg/Quark.dsc -a IA32 -t GCC48 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -ls Build/Quark/DEBUG_GCC48/FV/Quark.fd -</code></pre> - </li> - <li>Windows: -<pre><code>build -p QuarkPlatformPkg/Quark.dsc -a IA32 -t VS2012x86 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -dir Build\Quark\DEBUG_VS2012x86\FV\Quark.fd -</code></pre> - </li> - </ul> - </li> -</ol> - -<p> -Documentation: -</p> -<ul> - <li><a target="_blank" href="https://github.com/tianocore/edk2/tree/master/QuarkPlatformPkg">EDK II firmware for Intel® Quark™ SoC X1000 based platforms</a></li> - <li>Intel® Quark™ SoC X1000 <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/guides/quark-x1000-uefi-firmware-writers-guide.pdf">UEFI Firmware Writer's Guide</a></li> -</ul> - - - -<hr> -<p>Modified: 17 May 2016</p> - </body> -</html> diff --git a/Documentation/Intel/SoC/quark.md b/Documentation/Intel/SoC/quark.md new file mode 100644 index 0000000..2928b6e --- /dev/null +++ b/Documentation/Intel/SoC/quark.md @@ -0,0 +1,176 @@ +Intel® Quark™ SoC +================= + ++-----------------------------------+-----------------------------------+ +| [ board: | +| embedded/16x9/edc-quark-block-dia | - [Overall](../development.html | +| gram-16x9.png){width="500"}](http | ) | +| ://www.intel.com/content/dam/www/ | development | +| public/us/en/images/embedded/16x9 | - [SoC](soc.html) support | +| /edc-quark-block-diagram-16x9.png | - [FSP 1.1](../fsp1_1.html) | +| ) | integration | +| | - [Board](../Board/board.html) | +| | support | +| | - [Quark™ FSP](#QuarkFsp) | +| | - [CorebootPayloadPkg](#Coreboo | +| | tPayloadPkg) | ++-----------------------------------+-----------------------------------+ + +------------------------------------------------------------------------ + +Quark™ Documentation +-------------------- + +- [Block + Diagram](http://www.intel.com/content/dam/www/public/us/en/images/embedded/16x9/edc-q...) +- [Specifications](http://www.intel.com/content/www/us/en/embedded/products/quark/specification...): + - [X1000](http://ark.intel.com/products/79084/Intel-Quark-SoC-X1000-16K-Cache-400-MHz) - + [Documentation](http://www.intel.com/content/www/us/en/search.html?keyword=X1000): + - [Datasheet](http://www.intel.com/content/dam/www/public/us/en/documents/datasheets/quark...) + - [Developer's + Manual](http://www.intel.com/content/dam/support/us/en/documents/processors/quark/sb...) + - [Product + Brief](http://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/i...) +- [More documentation](../index.html#Documentation) + +------------------------------------------------------------------------ + +[Quark™ EDK2 CorebootPayloadPkg]{#CorebootPayloadPkg} +----------------------------------------------------- + +Build Instructions: + +1. Set up [build environment](#BuildEnvironment) +2. Linux (assumes GCC48): + + build -p CorebootPayloadPkg/CorebootPayloadPkgIa32.dsc -a IA32 \ + -t GCC48 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 \ + -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -DSHELL_TYPE=BUILD_SHELL \ + -DMAX_LOGICAL_PROCESSORS=1 + ls Build/CorebootPayloadPkgIA32/DEBUG_GCC48/FV/UEFIPAYLOAD.fd + +3. Windows (assumes Visual Studio 2015): + + build -p CorebootPayloadPkg\CorebootPayloadPkgIa32.dsc -a IA32 -t VS2015x86 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 -DSHELL_TYPE=BUILD_SHELL -DMAX_LOGICAL_PROCESSORS=1 + dir Build\CorebootPayloadPkgIA32\DEBUG_VS2015x86\FV\UEFIPAYLOAD.fd + +4. In the .config for coreboot, set the following Kconfig values: + - CONFIG_PAYLOAD_ELF=y + - CONFIG_PAYLOAD_FILE="path to UEFIPAYLOAD.fd" +5. Build coreboot +6. Copy the image build/coreboot.rom into flash + +------------------------------------------------------------------------ + +[Quark™ EDK2 Build Environment]{#BuildEnvironment} +-------------------------------------------------- + +Use the following steps to setup a build environment: + +1. Get the EDK2 sources: + A. EDK2: git clone https://github.com/tianocore/edk2.git + B. EDK2-non-osi: git clone + https://github.com/tianocore/edk2-non-osi.git + C. Win32 BaseTools: git clone + https://github.com/tianocore/edk2-BaseTools-win32.git +2. Set up a build window: + - Linux: + + export WORKSPACE=$PWD + export PACKAGES_PATH="$PWD/edk2:$PWD/edk2-non-osi" + cd edk2 + export WORKSPACE=$PWD + . edksetup.sh + + - Windows: + + set WORKSPACE=%CD% + set PACKAGES_PATH=%WORKSPACE%\edk2;%WORKSPACE%\edk2-non-osi + set EDK_TOOLS_BIN=%WORKSPACE%\edk2-BaseTools-win32 + cd edk2 + edksetup.bat + +------------------------------------------------------------------------ + +[Quark™ FSP]{#QuarkFsp} +----------------------- + +Getting the Quark FSP source: + +1. Set up an EDK-II [Build Environment](#BuildEnvironment) +2. cd edk2 +3. mkdir QuarkFspPkg +4. cd QuarkFspPkg +5. Use git to clone + [QuarkFspPkg](https://review.gerrithub.io/#/admin/projects/LeeLeahy/quarkfsp) + into the QuarkFpsPkg directory (.) + +### Building QuarkFspPkg + +There are two versions of FSP: FSP 1.1 and FSP 2.0. There are also two +different implementations of FSP, one using subroutines without SEC and +PEI core and the original implementation which relies on SEC and PEI +core. Finally there are two different build x86 types release (r32) and +debug (d32). + +Note that the subroutine implementations are a **work in progress**. + +Build commands shown building debug FSP: + +- Linux: + - QuarkFspPkg/BuildFsp1_1.sh -d32 + - QuarkFspPkg/BuildFsp1_1Pei.sh -d32 + - QuarkFspPkg/BuildFsp2_0.sh -d32 + - QuarkFspPkg/BuildFsp2_0Pei.sh -d32 +- Windows: + - QuarkFspPkg/BuildFsp1_1.bat -d32 + - Windows: QuarkFspPkg/BuildFsp2_0.bat -d32 + +### Copying FSP files into coreboot Source Tree + +There are some helper scripts to copy the FSP output into the coreboot +source tree. The parameters to these scripts are: + +1. EDK2 tree root +2. coreboot tree root +3. Build type: DEBUG or RELEASE + +Script files: + +- Linux: + - QuarkFspPkg/coreboot_fsp1_1.sh + - QuarkFspPkg/coreboot_fsp1_1Pei.sh + - QuarkFspPkg/coreboot_fsp2_0.sh + - QuarkFspPkg/coreboot_fsp2_0Pei.sh + +------------------------------------------------------------------------ + +Quark™ EDK2 BIOS +---------------- + +Build Instructions: + +1. Set up [build environment](#BuildEnvironment) +2. Build the image: + - Linux: + + build -p QuarkPlatformPkg/Quark.dsc -a IA32 -t GCC48 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 + ls Build/Quark/DEBUG_GCC48/FV/Quark.fd + + - Windows: + + build -p QuarkPlatformPkg/Quark.dsc -a IA32 -t VS2012x86 -b DEBUG -DDEBUG_PROPERTY_MASK=0x27 -DDEBUG_PRINT_ERROR_LEVEL=0x80000042 + dir Build\Quark\DEBUG_VS2012x86\FV\Quark.fd + +Documentation: + +- [EDK II firmware for Intel® Quark™ SoC X1000 based + platforms](https://github.com/tianocore/edk2/tree/master/QuarkPlatformPkg) +- Intel® Quark™ SoC X1000 [UEFI Firmware Writer's + Guide](http://www.intel.com/content/dam/www/public/us/en/documents/guides/quark-x10...) + +------------------------------------------------------------------------ + +Modified: 17 May 2016 diff --git a/Documentation/Intel/SoC/soc.html b/Documentation/Intel/SoC/soc.html deleted file mode 100644 index fff536b..0000000 --- a/Documentation/Intel/SoC/soc.html +++ /dev/null @@ -1,731 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>SoC</title> - </head> - <body> - -<h1>x86 System on a Chip (SoC) Development</h1> -<p> - SoC development is best done in parallel with development for a specific - board. The combined steps are listed - <a target="_blank" href="../development.html">here</a>. - The development steps for the SoC are listed below: -</p> -<ol> - <li><a target="_blank" href="../fsp1_1.html#RequiredFiles">FSP 1.1</a> required files</li> - <li>SoC <a href="#RequiredFiles">Required Files</a></li> - <li><a href="#Descriptor">Start Booting</a></li> - <li><a href="#EarlyDebug">Early Debug</a></li> - <li><a href="#Bootblock">Bootblock</a></li> - <li><a href="#TempRamInit">TempRamInit</a></li> - <li><a href="#Romstage">Romstage</a> - <ol type="A"> - <li>Enable <a href="#SerialOutput">Serial Output"</a></li> - <li>Get the <a href="#PreviousSleepState">Previous Sleep State</a></li> - <li>Add the <a href="#MemoryInit">MemoryInit</a> Support</li> - <li>Disable the <a href="#DisableShadowRom">Shadow ROM</a></li> - </ol> - </li> - <li><a href="#Ramstage">Ramstage</a> - <ol type="A"> - <li><a href="#DeviceTree">Start Device Tree Processing</a></li> - <li>Set up the <a href="#MemoryMap">Memory Map"</a></li> - </ol> - </li> - <li><a href="#AcpiTables">ACPI Tables</a></li> - <li><a href="#LegacyHardware">Legacy Hardware</a></li> -</ol> - - -<hr> -<h2><a name="RequiredFiles">Required Files</a></h2> -<p> - Create the directory as src/soc/<Vendor>/<Chip Family>. -</p> - -<p> - The following files are required to build a new SoC: -</p> -<ul> - <li>Include files - <ul> - <li>include/soc/pei_data.h</li> - <li>include/soc/pm.h</li> - </ul> - </li> - <li>Kconfig - Defines the Kconfig value for the SoC and selects the tool - chains for the various stages: - <ul> - <li>select ARCH_BOOTBLOCK_<Tool Chain></li> - <li>select ARCH_RAMSTAGE_<Tool Chain></li> - <li>select ARCH_ROMSTAGE_<Tool Chain></li> - <li>select ARCH_VERSTAGE_<Tool Chain></li> - </ul> - </li> - <li>Makefile.inc - Specify the include paths</li> - <li>memmap.c - Top of usable RAM</li> -</ul> - - -<hr> -<h2><a name="Descriptor">Start Booting</a></h2> -<p> - Some SoC parts require additional firmware components in the flash. - This section describes how to add those pieces. -</p> - -<h3>Intel Firmware Descriptor</h3> -<p> - The Intel Firmware Descriptor (IFD) is located at the base of the flash part. - The following command overwrites the base of the flash image with the Intel - Firmware Descriptor: -</p> -<pre><code>dd if=descriptor.bin of=build/coreboot.rom conv=notrunc >/dev/null 2>&1</code></pre> - - -<h3><a name="MEB">Management Engine Binary</a></h3> -<p> - Some SoC parts contain and require that the Management Engine (ME) be running - before it is possible to bring the x86 processor out of reset. A binary file - containing the management engine code must be added to the firmware using the - ifdtool. The following commands add this binary blob: -</p> -<pre><code>util/ifdtool/ifdtool -i ME:me.bin build/coreboot.rom -mv build/coreboot.rom.new build/coreboot.rom -</code></pre> - - -<h3><a name="EarlyDebug">Early Debug</a></h3> -<p> - Early debugging between the reset vector and the time the serial port is enabled - is most easily done by writing values to port 0x80. -</p> - - -<h3>Success</h3> -<p> - When the reset vector is successfully invoked, port 0x80 will output the following value: -</p> -<ul> - <li>0x01: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l45">POST_RESET_VECTOR_CORRECT</a> - - Bootblock successfully executed the - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/reset16.inc;hb=HEAD#l4">reset vector</a> - and entered the 16-bit code at - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/entry16.inc;hb=HEAD#l35">_start</a> - </li> -</ul> - - -<hr> -<h2><a name="Bootblock">Bootblock</a></h2> -<p> - Implement the bootblock using the following steps: -</p> -<ol> - <li>Create the directory as src/soc/<Vendor>/<Chip Family>/bootblock</li> - <li>Add the timestamp.inc file which initializes the floating point registers and saves - the initial timestamp. - </li> - <li>Add the bootblock.c file which: - <ol type="A"> - <li>Enables memory-mapped PCI config access</li> - <li>Updates the microcode by calling intel_update_microcode_from_cbfs</li> - <li>Enable ROM caching</li> - </ol> - </li> - <li>Edit the src/soc/<Vendor>/<Chip Family>/Kconfig file - <ol type="A"> - <li>Add the BOOTBLOCK_CPU_INIT value to point to the bootblock.c file</li> - <li>Add the CHIPSET_BOOTBLOCK_INCLUDE value to point to the timestamp.inc file</li> - </ol> - </li> - <li>Edit the src/soc/<Vendor>/<Chip Family>/Makefile.inc file - <ol type="A"> - <li>Add the bootblock subdirectory</li> - </ol> - </li> - <li>Edit the src/soc/<Vendor>/<Chip Family>/memmap.c file - <ol type="A"> - <li>Add the fsp/memmap.h include file</li> - <li>Add the mmap_region_granularity routine</li> - </ol> - </li> - <li>Add the necessary .h files to define the necessary values and structures</li> - <li>When successful port 0x80 will output the following values: - <ol type="A"> - <li>0x01: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l45">POST_RESET_VECTOR_CORRECT</a> - - Bootblock successfully executed the - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/reset16.inc;hb=HEAD#l4">reset vector</a> - and entered the 16-bit code at - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/entry16.inc;hb=HEAD#l35">_start</a> - </li> - <li>0x10: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l53">POST_ENTER_PROTECTED_MODE</a> - - Bootblock executing in - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/32bit/entry32.inc;hb=HEAD#l55">32-bit mode</a> - </li> - <li>0x10 - Verstage/romstage reached 32-bit mode</li> - </ol> - </li> -</ol> - -<p> - <b>Build Note:</b> The following files are included into the default bootblock image: -</p> -<ul> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/bootblock_romcc.S;hb=HEAD">src/arch/x86/bootblock_romcc.S</a> - added by <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Makefile.inc;hb=HEAD#l133">src/arch/x86/Makefile.inc</a> - and includes the following files: - <ul> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/prologue.inc">src/arch/x86/prologue.inc</a></li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/reset16.inc">src/cpu/x86/16bit/reset16.inc</a></li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit/entry16.inc">src/cpu/x86/16bit/entry16.inc</a></li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/32bit/entry32.inc">src/cpu/x86/32bit/entry32.inc</a></li> - <li>The code in - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/bootblock_romcc.S">src/arch/x86/bootblock_romcc.S</a> - includes src/soc/<Vendor>/<Chip Family>/bootblock/timestamp.inc using the - CONFIG_CHIPSET_BOOTBLOCK_INCLUDE value set above - </li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/sse_enable.inc">src/cpu/x86/sse_enable.inc</a></li> - <li>The code in - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Makefile.inc;hb=HEAD#l156">src/arch/x86/Makefile.inc</a> - invokes the ROMCC tool to convert the following "C" code into assembler as bootblock.inc: - <ul> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/include/arch/bootblock_romcc.h">src/arch/x86/include/arch/bootblock_romcc.h</a></li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/lapic/boot_cpu.c">src/cpu/x86/lapic/boot_cpu.c</a></li> - <li>The CONFIG_BOOTBLOCK_CPU_INIT value set above typically points to the code in - src/soc/<Vendor>/<Chip Family>/bootblock/bootblock.c - </li> - </ul> - </li> - </ul> - </li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/id.S">src/arch/x86/id.S</a> - added by <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Makefile.inc;hb=HEAD#l110">src/arch/x86/Makefile.inc</a> - </li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/intel/fit/fit.S">src/cpu/intel/fit/fit.S</a> - added by <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/intel/fit/Makefile.inc;hb=HEAD">src/cpu/intel/fit/Makefile.inc</a> - </li> - <li><a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/walkcbfs.S">src/arch/x86/walkcbfs.S</a> - added by <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Makefile.inc;hb=HEAD#l137">src/arch/x86/Makefile.inc</a> - </li> -</ul> - - -<hr> -<h2><a name="TempRamInit">TempRamInit</a></h2> -<p> - Enable the call to TempRamInit in two stages: -</p> -<ol> - <li>Finding the FSP binary in the read-only CBFS region</li> - <li>Call TempRamInit</li> -</ol> - - -<h3>Find FSP Binary</h3> -<p> -Use the following steps to locate the FSP binary: -</p> -<ol> - <li>Edit the src/soc/<Vendor>/<Chip Family>/Kconfig file - <ol type="A"> - <li>Add "select USE_GENERIC_FSP_CAR_INC" to enable the use of - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc">src/drivers/intel/fsp1_1/cache_as_ram.inc</a> - </li> - <li>Add "select SOC_INTEL_COMMON" to enable the use of the files from src/soc/intel/common - </li> - </ol> - </li> - <li>Debug the result until port 0x80 outputs - <ol type="A"> - <li>0x90: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l205">POST_FSP_TEMP_RAM_INIT</a> - - Just before calling - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l73">TempRamInit</a> - </li> - <li>Alternating 0xba and 0x01 - The FSP image was not found</li> - </ol> - </li> - <li>Add the <a target="_blank" href="../fsp1_1.html#FspBinary">FSP binary file</a> to the flash image</li> - <li>Set the following Kconfig values: - <ul> - <li>CONFIG_FSP_LOC to the FSP base address specified in the previous step</li> - <li>CONFIG_FSP_IMAGE_ID_STRING</li> - </ul> - </li> - <li>Debug the result until port 0x80 outputs - <ol type="A"> - <li>0x90: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l205">POST_FSP_TEMP_RAM_INIT</a> - - Just before calling - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l73">TempRamInit</a> - </li> - <li>Alternating 0xbb and 0x02 - TempRamInit executed, no CPU microcode update found</li> - </ol> - </li> -</ol> - - -<h3>Calling TempRamInit</h3> -<p> -Use the following steps to debug the call to TempRamInit: -</p> -<ol> - <li>Add the CPU microcode update file - <ol type="A"> - <li>Add the microcode file with the following command -<pre><code>util/cbfstool/cbfstool build/coreboot.rom add -t microcode -n cpu_microcode_blob.bin -b <base address> -f cpu_microcode_blob.bin</code></pre> - </li> - <li>Set the Kconfig values - <ul> - <li>CONFIG_CPU_MICROCODE_CBFS_LOC set to the value from the previous step</li> - <li>CONFIG_CPU_MICROCODE_CBFS_LEN</li> - </ul> - </li> - </ol> - </li> - <li>Debug the result until port 0x80 outputs - <ol type="A"> - <li>0x90: <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l205">POST_FSP_TEMP_RAM_INIT</a> - - Just before calling - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l73">TempRamInit</a> - </li> - <li>0x2A - Just before calling - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l151">cache_as_ram_main</a> - which is the start of the verstage code which may be part of romstage - </li> - </ol> - </li> -</ol> - - -<hr> -<h2><a name="Romstage">Romstage</a></h2> - -<h3><a name="SerialOutput">Serial Output</a></h3> -<p> - The following steps add the serial output support for romstage: -</p> -<ol> - <li>Create the romstage subdirectory</li> - <li>Add romstage/romstage.c - <ol type="A"> - <li>Program the necessary base addresses</li> - <li>Disable the TCO</li> - </ol> - </li> - <li>Add romstage/Makefile.inc - <ol type="A"> - <li>Add romstage.c to romstage</li> - </ol> - </li> - <li>Add gpio configuration support if necessary</li> - <li>Add the necessary .h files to support the build</li> - <li>Update Makefile.inc - <ol type="A"> - <li>Add the romstage subdirectory</li> - <li>Add the gpio configuration support file to romstage</li> - </ol> - </li> - <li>Set the necessary Kconfig values to enable serial output: - <ul> - <li>CONFIG_DRIVERS_UART_<driver>=y</li> - <li>CONFIG_CONSOLE_SERIAL=y</li> - <li>CONFIG_UART_FOR_CONSOLE=<port></li> - <li>CONFIG_CONSOLE_SERIAL_115200=y</li> - </ul> - </li> -</ol> - - -<h3><a name="PreviousSleepState">Determine Previous Sleep State</a></h3> -<p> - The following steps implement the code to get the previous sleep state: -</p> -<ol> - <li>Implement the fill_power_state routine which determines the previous sleep state</li> - <li>Debug the result until port 0x80 outputs - <ol type="A"> - <li>0x32: - - Just after entering - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/romstage.c;hb=HEAD#l99">romstage_common</a> - </li> - <li>0x33 - Just after calling - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/romstage.c;hb=HEAD#l113">soc_pre_ram_init</a> - </li> - <li>0x34: - - Just after entering - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l67">raminit</a> - </li> - </ol> -</ol> - - -<h3><a name="MemoryInit">MemoryInit Support</a></h3> -<p> - The following steps implement the code to support the FSP MemoryInit call: -</p> -<ol> - <li>Add the chip.h header file to define the UPD values which get passed - to MemoryInit. Skip the values containing SPD addresses and DRAM - configuration data which is determined by the board. - <p> - <b>Build Note</b>: The src/mainboard/<Vendor>/<Board>/devicetree.cb - file specifies the default values for these parameters. The build - process creates the static.c module which contains the config data - structure containing these values. - </p> - </li> - <li>Edit romstage/romstage.c - <ol type="A"> - <li>Implement the romstage/romstage.c/soc_memory_init_params routine to - copy the values from the config structure into the UPD structure - </li> - <li>Implement the soc_display_memory_init_params routine to display - the updated UPD parameters by calling fsp_display_upd_value - </li> - </ol> - </li> -</ol> - - -<h3><a name="DisableShadowRom">Disable Shadow ROM</a></h3> -<p> - A shadow of the SPI flash part is mapped from 0x000e0000 to 0x000fffff. - This shadow needs to be disabled to allow RAM to properly respond to - this address range. -</p> -<ol> - <li>Edit romstage/romstage.c and add the soc_after_ram_init routine</li> -</ol> - - -<hr> -<h2><a name="Ramstage">Ramstage</a></h2> - -<h3><a name="DeviceTree">Start Device Tree Processing</a></h3> -<p> - The src/mainboard/<Vendor>/<Board>/devicetree.cb file drives the - execution during ramstage. This file is processed by the util/sconfig utility - to generate build/mainboard/<Vendor>/<Board>/static.c. The various - state routines in - src/lib/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/lib/hardwaremain.c;hb=HEAD#l128">hardwaremain.c</a> - call dev_* routines which use the tables in static.c to locate operation tables - associated with the various chips and devices. After location the operation - tables, the state routines call one or more functions depending upon the - state of the state machine. -</p> - -<h4><a name="ChipOperations">Chip Operations</a></h4> -<p> - Kick-starting the ramstage state machine requires creating the operation table - for the chip listed in devicetree.cb: -</p> -<ol> - <li>Edit src/soc/<SoC Vendor>/<SoC Family>/chip.c: - <ol type="A"> - <li> - This chip's operation table has the name - soc_<SoC Vendor>_<SoC Family>_ops which is derived from the - chip path specified in the devicetree.cb file. - </li> - <li>Use the CHIP_NAME macro to specify the name for the chip</li> - <li>For FSP 1.1, specify a .init routine which calls intel_silicon_init</li> - </ol> - </li> - <li>Edit src/soc/<SoC Vendor>/<SoC Family>/Makefile.inc and add chip.c to ramstage</li> -</ol> - -<h4>Domain Operations</h4> -<p> - coreboot uses the domain operation table to initiate operations on all of the - devices in the domain. By default coreboot enables all PCI devices which it - finds. Listing a device in devicetree.cb gives the board vendor control over - the device state. Non-PCI devices may also be listed under PCI device such as - the LPC bus or SMbus devices. -</p> -<ol> - <li>Edit src/soc/<SoC Vendor>/<SoC Family>/chip.c: - <ol type="A"> - <li> - The domain operation table is typically placed in - src/soc/<SoC Vendor>/<SoC Family>/chip.c. - The table typically looks like the following: -<pre><code>static struct device_operations pci_domain_ops = { - .read_resources = pci_domain_read_resources, - .set_resources = pci_domain_set_resources, - .scan_bus = pci_domain_scan_bus, -}; -</code></pre> - </li> - <li> - Create a .enable_dev entry in the chip operations table which points to a - routine which sets the domain table for the device with the DEVICE_PATH_DOMAIN. -<pre><code> if (dev->path.type == DEVICE_PATH_DOMAIN) { - dev->ops = &pci_domain_ops; - } -</code></pre> - </li> - <li> - During the BS_DEV_ENUMERATE state, ramstage now display the device IDs - for the PCI devices on the bus. - </li> - </ol> - </li> - <li>Set CONFIG_DEBUG_BOOT_STATE=y in the .config file</li> - <li> - Debug the result until the PCI vendor and device IDs are displayed - during the BS_DEV_ENUMERATE state. - </li> -</ol> - - -<h3><a name="DeviceDrivers">PCI Device Drivers</a></h3> -<p> - PCI device drivers consist of a ".c" file which contains a "pci_driver" data - structure at the end of the file with the attribute tag "__pci_driver". This - attribute tag places an entry into a link time table listing the various - coreboot device drivers. -</p> -<p> - Specify the following fields in the table: -</p> -<ol> - <li>.vendor - PCI vendor ID value of the device</li> - <li>.device - PCI device ID value of the device or<br> - .devices - Address of a zero terminated array of PCI device IDs - </li> - <li>.ops - Operations table for the device. This is the address - of a "static struct device_operations" data structure specifying - the routines to execute during the different states and sub-states - of ramstage's processing. - </li> - <li>Turn on the device in mainboard/<Vendor>/<Board>/devicetree.cb</li> - <li> - Debug until the device is on and properly configured in coreboot and - usable by the payload - </li> -</ol> - -<h4><a name="SubsystemIds">Subsystem IDs</a></h4> -<p> - PCI subsystem IDs are assigned during the BS_DEV_ENABLE state. The device - driver may use the common mechanism to assign subsystem IDs by adding - the ".ops_pci" to the pci_driver data structure. This field points to - a "struct pci_operations" that specifies a routine to set the subsystem - IDs for the device. The routine might look something like this: -</p> -<pre><code>static void pci_set_subsystem(struct device *dev, unsigned vendor, unsigned device) -{ - if (!vendor || !device) { - vendor = pci_read_config32(dev, PCI_VENDOR_ID); - device = vendor >> 16; - } - printk(BIOS_SPEW, - "PCI: %02x:%02x:%d subsystem vendor: 0x%04x, device: 0x%04x\n", - 0, PCI_SLOT(dev->path.pci.devfn), PCI_FUNC(dev->path.pci.devfn), - vendor & 0xffff, device); - pci_write_config32(dev, PCI_SUBSYSTEM_VENDOR_ID, - ((device & 0xffff) << 16) | (vendor & 0xffff)); -} -</code></pre> - - - -<h3>Set up the <a name="MemoryMap">Memory Map</a></h3> -<p> - The memory map is built by the various PCI device drivers during the - BS_DEV_RESOURCES state of ramstage. The northcluster driver will typically - specify the DRAM resources while the other drivers will typically specify - the IO resources. These resources are hung off the struct device *data structure by - src/device/device_util.c/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/device/device_util.c;hb=HEAD#l448">new_resource</a>. -</p> -<p> - During the BS_WRITE_TABLES state, coreboot collects these resources and - places them into a data structure identified by LB_MEM_TABLE. -</p> -<p> - Edit the device driver file: -</p> -<ol> - <li> - Implement a read_resources routine which calls macros defined in - src/include/device/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/device/device.h;hb=HEAD#l237">device.h</a> - like: - <ul> - <li>ram_resource</li> - <li>reserved_ram_resource</li> - <li>bad_ram_resource</li> - <li>uma_resource</li> - <li>mmio_resource</li> - </ul> - </li> -</ol> - -<p> - Testing: Verify that the resources are properly displayed by coreboot during the BS_WRITE_TABLES state. -</p> - - - -<hr> -<h2><a name="AcpiTables">ACPI Tables</a></h2> -<p> - One of the payloads that needs ACPI tables is the EDK2 <a target="_blank" href="quark.html#CorebootPayloadPkg">CorebootPayloadPkg</a>. -</p> - -<h3>FADT</h3> -<p> - The EDK2 module - CorebootModulePkg/Library/CbParseLib/<a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/Library/CbParseLib/CbParseLib.c#l450">CbParseLib.c</a> - requires that the FADT contains the values in the table below. - These values are placed into a HOB identified by - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/CorebootModulePkg.dec#l36">gUefiAcpiBoardInfoGuid</a> - by routine - CorebootModulePkg/CbSupportPei/CbSupportPei/<a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/CbSupportPei/CbSupportPei.c#l364">CbPeiEntryPoint</a>. -</p> -<table border="1"> - <tr bgcolor="#c0ffc0"> - <td>coreboot Field</td> - <td>EDK2 Field</td> - <td>gUefiAcpiBoardInfoGuid</td> - <td>Use</li> - <td> - <a target="_blank" href="http://www.uefi.org/sites/default/files/resources/ACPI_6.0.pdf">ACPI Spec.</a> - Section - </td> - </tr> - <tr> - <td>gpe0_blk<br>gpe0_blk_len</td> - <td>Gpe0Blk<br>Gpe0BlkLen</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/Library/CbParseLib/CbParseLib.c#l477">PmGpeEnBase</a> - </td> - <td><a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l129">Shutdown</a></td> - <td>4.8.4.1</td> - </tr> - <tr> - <td>pm1a_cnt_blk</td> - <td>Pm1aCntBlk</td> - <td>PmCtrlRegBase</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l139">Shutdown</a><br> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l40">Suspend</a> - </td> - <td>4.8.3.2.1</td> - </tr> - <tr> - <td>pm1a_evt_blk</td> - <td>Pm1aEvtBlk</td> - <td>PmEvtBase</td> - <td><a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l134">Shutdown</a></td> - <td>4.8.3.1.1</td> - </tr> - <tr> - <td>pm_tmr_blk</td> - <td>PmTmrBlk</td> - <td>PmTimerRegBase</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/AcpiTimerLib/AcpiTimerLib.c#l55">Timer</a> - </td> - <td>4.8.3.3</td> - </tr> - <tr> - <td>reset_reg.</td> - <td>ResetReg.Address</td> - <td>ResetRegAddress</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l71">Cold</a> - and - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l98">Warm</a> - resets - </td> - <td>4.3.3.6</td> - </tr> - <tr> - <td>reset_value</td> - <td>ResetValue</td> - <td>ResetValue</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l71">Cold</a> - and - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/ResetSystemLib/ResetSystemLib.c#l98">Warm</a> - resets - </td> - <td>4.8.3.6</td> - </tr> -</table> -<p> - The EDK2 data structure is defined in - MdeModulePkg/Include/IndustryStandard/<a target="_blank" href="https://github.com/tianocore/edk2/blob/master/MdePkg/Include/IndustryStandard/Acpi61.h#l111">Acpi61.h</a> - The coreboot data structure is defined in - src/arch/x86/include/arch/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/include/arch/acpi.h;hb=HEAD#l237">acpi.h</a> -</p> - -<ol> - <li> - Select <a target="_blank" href="../Board/board.html#AcpiTables">HAVE_ACPI_TABLES</a> - in the board's Kconfig file - </li> - <li>Create a acpi.c module: - <ol type="A"> - <li>Add the acpi_fill_in_fadt routine and initialize the values above</li> - </ol> - </li> -</ol> - - - -<hr> -<h2><a name="LegacyHardware">Legacy Hardware</a></h2> -<p> - One of the payloads that needs legacy hardare is the EDK2 <a target="_blank" href="quark.html#CorebootPayloadPkg">CorebootPayloadPkg</a>. -</p> - -<table border="1"> - <tr bgcolor="c0ffc0"> - <th>Peripheral</th> - <th>Use</th> - <th>8259 Interrupt Vector</th> - <th>IDT Base Offset</th> - <th>Interrupt Handler</th> - </tr> - <tr> - <td> - <a target="_blank" href="http://www.scs.stanford.edu/10wi-cs140/pintos/specs/8254.pdf">8254</a> - Programmable Interval Timer - </td> - <td> - EDK2: PcAtChipsetPkg/8254TimerDxe/<a target="_blank" href="https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8254TimerDxe/Timer.c">Timer.c</a> - </td> - <td>0</td> - <td>0x340</td> - <td> - <a target="_blank" href="https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8254TimerDxe/Timer.c#l71">TimerInterruptHandler</a> - </td> - </tr> - <tr> - <td> - <a target="_blank" href="https://www.google.com/url?sa=t&rct=j&q=&esrc=s&source=web&cd=1&cad=rja&uact=8&ved=0ahUKEwibxYKU3ZDLAhVOzWMKHfuqB40QFggcMAA&url=http%3A%2F%2Fbochs.sourceforge.net%2Ftechspec%2Fintel-8259a-pic.pdf.gz&usg=AFQjCNF1NT0OQ6ys1Pn6Iv9sv6cKRzZbGg&sig2=HfBszp9xTVO_fajjPWCsJw">8259</a> - Programmable Interrupt Controller - </td> - <td> - EDK2: PcAtChipsetPkg/8259InterruptControllerDxe/<a target="_blank" href="https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8259InterruptControllerDxe/8259.c">8259.c</a> - </td> - <td> - Master interrupts: 0, 2 - 7<br> - Slave interrupts: 8 - 15<br> - Interrupt vector 1 is never generated, the cascaded input generates interrupts 8 - 15 - </td> - <td> - Master: 0x340, 0x350 - 0x378<br> - Slave: 0x380 - 0x3b8<br> - Interrupt descriptors are 8 bytes each - </td> - <td> </td> - </tr> -</table> - -<hr> -<p>Modified: 4 March 2016</p> - </body> -</html> diff --git a/Documentation/Intel/SoC/soc.md b/Documentation/Intel/SoC/soc.md new file mode 100644 index 0000000..08af994 --- /dev/null +++ b/Documentation/Intel/SoC/soc.md @@ -0,0 +1,508 @@ +x86 System on a Chip (SoC) Development +====================================== + +SoC development is best done in parallel with development for a specific +board. The combined steps are listed [here](../development.html). The +development steps for the SoC are listed below: + +1. [FSP 1.1](../fsp1_1.html#RequiredFiles) required files +2. SoC [Required Files](#RequiredFiles) +3. [Start Booting](#Descriptor) +4. [Early Debug](#EarlyDebug) +5. [Bootblock](#Bootblock) +6. [TempRamInit](#TempRamInit) +7. [Romstage](#Romstage) + A. Enable [Serial Output"](#SerialOutput) + B. Get the [Previous Sleep State](#PreviousSleepState) + C. Add the [MemoryInit](#MemoryInit) Support + D. Disable the [Shadow ROM](#DisableShadowRom) +8. [Ramstage](#Ramstage) + A. [Start Device Tree Processing](#DeviceTree) + B. Set up the [Memory Map"](#MemoryMap) +9. [ACPI Tables](#AcpiTables) +10. [Legacy Hardware](#LegacyHardware) + +------------------------------------------------------------------------ + +[Required Files]{#RequiredFiles} +-------------------------------- + +Create the directory as src/soc/<Vendor>/<Chip Family>. + +The following files are required to build a new SoC: + +- Include files + - include/soc/pei_data.h + - include/soc/pm.h +- Kconfig - Defines the Kconfig value for the SoC and selects the tool + chains for the various stages: + - select ARCH_BOOTBLOCK_<Tool Chain> + - select ARCH_RAMSTAGE_<Tool Chain> + - select ARCH_ROMSTAGE_<Tool Chain> + - select ARCH_VERSTAGE_<Tool Chain> +- Makefile.inc - Specify the include paths +- memmap.c - Top of usable RAM + +------------------------------------------------------------------------ + +[Start Booting]{#Descriptor} +---------------------------- + +Some SoC parts require additional firmware components in the flash. This +section describes how to add those pieces. + +### Intel Firmware Descriptor + +The Intel Firmware Descriptor (IFD) is located at the base of the flash +part. The following command overwrites the base of the flash image with +the Intel Firmware Descriptor: + + dd if=descriptor.bin of=build/coreboot.rom conv=notrunc >/dev/null 2>&1 + +### [Management Engine Binary]{#MEB} + +Some SoC parts contain and require that the Management Engine (ME) be +running before it is possible to bring the x86 processor out of reset. A +binary file containing the management engine code must be added to the +firmware using the ifdtool. The following commands add this binary blob: + + util/ifdtool/ifdtool -i ME:me.bin build/coreboot.rom + mv build/coreboot.rom.new build/coreboot.rom + +### [Early Debug]{#EarlyDebug} + +Early debugging between the reset vector and the time the serial port is +enabled is most easily done by writing values to port 0x80. + +### Success + +When the reset vector is successfully invoked, port 0x80 will output the +following value: + +- 0x01: + [POST_RESET_VECTOR_CORRECT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Bootblock successfully executed the [reset + vector](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + and entered the 16-bit code at + [_start](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + +------------------------------------------------------------------------ + +[Bootblock]{#Bootblock} +----------------------- + +Implement the bootblock using the following steps: + +1. Create the directory as src/soc/<Vendor>/<Chip + Family>/bootblock +2. Add the timestamp.inc file which initializes the floating point + registers and saves the initial timestamp. +3. Add the bootblock.c file which: + A. Enables memory-mapped PCI config access + B. Updates the microcode by calling + intel_update_microcode_from_cbfs + C. Enable ROM caching +4. Edit the src/soc/<Vendor>/<Chip Family>/Kconfig file + A. Add the BOOTBLOCK_CPU_INIT value to point to the bootblock.c + file + B. Add the CHIPSET_BOOTBLOCK_INCLUDE value to point to the + timestamp.inc file +5. Edit the src/soc/<Vendor>/<Chip Family>/Makefile.inc + file + A. Add the bootblock subdirectory +6. Edit the src/soc/<Vendor>/<Chip Family>/memmap.c file + A. Add the fsp/memmap.h include file + B. Add the mmap_region_granularity routine +7. Add the necessary .h files to define the necessary values and + structures +8. When successful port 0x80 will output the following values: + A. 0x01: + [POST_RESET_VECTOR_CORRECT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Bootblock successfully executed the [reset + vector](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + and entered the 16-bit code at + [_start](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + B. 0x10: + [POST_ENTER_PROTECTED_MODE](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Bootblock executing in [32-bit + mode](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/32bit...) + C. 0x10 - Verstage/romstage reached 32-bit mode + +**Build Note:** The following files are included into the default +bootblock image: + +- [src/arch/x86/bootblock_romcc.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/boot...) + added by + [src/arch/x86/Makefile.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Make...) + and includes the following files: + - [src/arch/x86/prologue.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/prol...) + - [src/cpu/x86/16bit/reset16.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + - [src/cpu/x86/16bit/entry16.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/16bit...) + - [src/cpu/x86/32bit/entry32.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/32bit...) + - The code in + [src/arch/x86/bootblock_romcc.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/boot...) + includes src/soc/<Vendor>/<Chip + Family>/bootblock/timestamp.inc using the + CONFIG_CHIPSET_BOOTBLOCK_INCLUDE value set above + - [src/cpu/x86/sse_enable.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/sse_e...) + - The code in + [src/arch/x86/Makefile.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Make...) + invokes the ROMCC tool to convert the following "C" code into + assembler as bootblock.inc: + - [src/arch/x86/include/arch/bootblock_romcc.h](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/incl...) + - [src/cpu/x86/lapic/boot_cpu.c](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/x86/lapic...) + - The CONFIG_BOOTBLOCK_CPU_INIT value set above typically + points to the code in src/soc/<Vendor>/<Chip + Family>/bootblock/bootblock.c +- [src/arch/x86/id.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/id.S) + added by + [src/arch/x86/Makefile.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Make...) +- [src/cpu/intel/fit/fit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/intel/fit...) + added by + [src/cpu/intel/fit/Makefile.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/cpu/intel/fit...) +- [src/arch/x86/walkcbfs.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/walk...) + added by + [src/arch/x86/Makefile.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/Make...) + +------------------------------------------------------------------------ + +[TempRamInit]{#TempRamInit} +--------------------------- + +Enable the call to TempRamInit in two stages: + +1. Finding the FSP binary in the read-only CBFS region +2. Call TempRamInit + +### Find FSP Binary + +Use the following steps to locate the FSP binary: + +1. Edit the src/soc/<Vendor>/<Chip Family>/Kconfig file + A. Add "select USE_GENERIC_FSP_CAR_INC" to enable the use of + [src/drivers/intel/fsp1_1/cache_as_ram.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. Add "select SOC_INTEL_COMMON" to enable the use of the files + from src/soc/intel/common +2. Debug the result until port 0x80 outputs + A. 0x90: + [POST_FSP_TEMP_RAM_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Just before calling + [TempRamInit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. Alternating 0xba and 0x01 - The FSP image was not found +3. Add the [FSP binary file](../fsp1_1.html#FspBinary) to the flash + image +4. Set the following Kconfig values: + - CONFIG_FSP_LOC to the FSP base address specified in the + previous step + - CONFIG_FSP_IMAGE_ID_STRING +5. Debug the result until port 0x80 outputs + A. 0x90: + [POST_FSP_TEMP_RAM_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Just before calling + [TempRamInit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. Alternating 0xbb and 0x02 - TempRamInit executed, no CPU + microcode update found + +### Calling TempRamInit + +Use the following steps to debug the call to TempRamInit: + +1. Add the CPU microcode update file + A. Add the microcode file with the following command + + util/cbfstool/cbfstool build/coreboot.rom add -t microcode -n cpu_microcode_blob.bin -b <base address> -f cpu_microcode_blob.bin + + B. Set the Kconfig values + - CONFIG_CPU_MICROCODE_CBFS_LOC set to the value from the + previous step + - CONFIG_CPU_MICROCODE_CBFS_LEN + +2. Debug the result until port 0x80 outputs + A. 0x90: + [POST_FSP_TEMP_RAM_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...) - + Just before calling + [TempRamInit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. 0x2A - Just before calling + [cache_as_ram_main](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + which is the start of the verstage code which may be part of + romstage + +------------------------------------------------------------------------ + +[Romstage]{#Romstage} +--------------------- + +### [Serial Output]{#SerialOutput} + +The following steps add the serial output support for romstage: + +1. Create the romstage subdirectory +2. Add romstage/romstage.c + A. Program the necessary base addresses + B. Disable the TCO +3. Add romstage/Makefile.inc + A. Add romstage.c to romstage +4. Add gpio configuration support if necessary +5. Add the necessary .h files to support the build +6. Update Makefile.inc + A. Add the romstage subdirectory + B. Add the gpio configuration support file to romstage +7. Set the necessary Kconfig values to enable serial output: + - CONFIG_DRIVERS_UART_<driver>=y + - CONFIG_CONSOLE_SERIAL=y + - CONFIG_UART_FOR_CONSOLE=<port> + - CONFIG_CONSOLE_SERIAL_115200=y + +### [Determine Previous Sleep State]{#PreviousSleepState} + +The following steps implement the code to get the previous sleep state: + +1. Implement the fill_power_state routine which determines the + previous sleep state +2. Debug the result until port 0x80 outputs + A. 0x32: - Just after entering + [romstage_common](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + B. 0x33 - Just after calling + [soc_pre_ram_init](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + C. 0x34: - Just after entering + [raminit](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + +### [MemoryInit Support]{#MemoryInit} + +The following steps implement the code to support the FSP MemoryInit +call: + +1. Add the chip.h header file to define the UPD values which get passed + to MemoryInit. Skip the values containing SPD addresses and DRAM + configuration data which is determined by the board. + + **Build Note**: The + src/mainboard/<Vendor>/<Board>/devicetree.cb file + specifies the default values for these parameters. The build process + creates the static.c module which contains the config data structure + containing these values. + +2. Edit romstage/romstage.c + A. Implement the romstage/romstage.c/soc_memory_init_params + routine to copy the values from the config structure into the + UPD structure + B. Implement the soc_display_memory_init_params routine to + display the updated UPD parameters by calling + fsp_display_upd_value + +### [Disable Shadow ROM]{#DisableShadowRom} + +A shadow of the SPI flash part is mapped from 0x000e0000 to 0x000fffff. +This shadow needs to be disabled to allow RAM to properly respond to +this address range. + +1. Edit romstage/romstage.c and add the soc_after_ram_init routine + +------------------------------------------------------------------------ + +[Ramstage]{#Ramstage} +--------------------- + +### [Start Device Tree Processing]{#DeviceTree} + +The src/mainboard/<Vendor>/<Board>/devicetree.cb file drives +the execution during ramstage. This file is processed by the +util/sconfig utility to generate +build/mainboard/<Vendor>/<Board>/static.c. The various state +routines in +src/lib/[hardwaremain.c](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/lib/hardwarem...) +call dev_* routines which use the tables in static.c to locate +operation tables associated with the various chips and devices. After +location the operation tables, the state routines call one or more +functions depending upon the state of the state machine. + +#### [Chip Operations]{#ChipOperations} + +Kick-starting the ramstage state machine requires creating the operation +table for the chip listed in devicetree.cb: + +1. Edit src/soc/<SoC Vendor>/<SoC Family>/chip.c: + A. This chip's operation table has the name soc_<SoC + Vendor>_<SoC Family>_ops which is derived from the + chip path specified in the devicetree.cb file. + B. Use the CHIP_NAME macro to specify the name for the chip + C. For FSP 1.1, specify a .init routine which calls + intel_silicon_init +2. Edit src/soc/<SoC Vendor>/<SoC Family>/Makefile.inc and + add chip.c to ramstage + +#### Domain Operations + +coreboot uses the domain operation table to initiate operations on all +of the devices in the domain. By default coreboot enables all PCI +devices which it finds. Listing a device in devicetree.cb gives the +board vendor control over the device state. Non-PCI devices may also be +listed under PCI device such as the LPC bus or SMbus devices. + +1. Edit src/soc/<SoC Vendor>/<SoC Family>/chip.c: + A. The domain operation table is typically placed in + src/soc/<SoC Vendor>/<SoC Family>/chip.c. The table + typically looks like the following: + + static struct device_operations pci_domain_ops = { + .read_resources = pci_domain_read_resources, + .set_resources = pci_domain_set_resources, + .scan_bus = pci_domain_scan_bus, + }; + + B. Create a .enable_dev entry in the chip operations table which + points to a routine which sets the domain table for the device + with the DEVICE_PATH_DOMAIN. + + if (dev->path.type == DEVICE_PATH_DOMAIN) { + dev->ops = &pci_domain_ops; + } + + C. During the BS_DEV_ENUMERATE state, ramstage now display the + device IDs for the PCI devices on the bus. + +2. Set CONFIG_DEBUG_BOOT_STATE=y in the .config file +3. Debug the result until the PCI vendor and device IDs are displayed + during the BS_DEV_ENUMERATE state. + +### [PCI Device Drivers]{#DeviceDrivers} + +PCI device drivers consist of a ".c" file which contains a "pci_driver" +data structure at the end of the file with the attribute tag +"__pci_driver". This attribute tag places an entry into a link time +table listing the various coreboot device drivers. + +Specify the following fields in the table: + +1. .vendor - PCI vendor ID value of the device +2. .device - PCI device ID value of the device or\ + .devices - Address of a zero terminated array of PCI device IDs +3. .ops - Operations table for the device. This is the address of a + "static struct device_operations" data structure specifying the + routines to execute during the different states and sub-states of + ramstage's processing. +4. Turn on the device in + mainboard/<Vendor>/<Board>/devicetree.cb +5. Debug until the device is on and properly configured in coreboot and + usable by the payload + +#### [Subsystem IDs]{#SubsystemIds} + +PCI subsystem IDs are assigned during the BS_DEV_ENABLE state. The +device driver may use the common mechanism to assign subsystem IDs by +adding the ".ops_pci" to the pci_driver data structure. This field +points to a "struct pci_operations" that specifies a routine to set the +subsystem IDs for the device. The routine might look something like +this: + + static void pci_set_subsystem(struct device *dev, unsigned vendor, unsigned device) + { + if (!vendor || !device) { + vendor = pci_read_config32(dev, PCI_VENDOR_ID); + device = vendor >> 16; + } + printk(BIOS_SPEW, + "PCI: %02x:%02x:%d subsystem vendor: 0x%04x, device: 0x%04x\n", + 0, PCI_SLOT(dev->path.pci.devfn), PCI_FUNC(dev->path.pci.devfn), + vendor & 0xffff, device); + pci_write_config32(dev, PCI_SUBSYSTEM_VENDOR_ID, + ((device & 0xffff) << 16) | (vendor & 0xffff)); + } + +### Set up the [Memory Map]{#MemoryMap} + +The memory map is built by the various PCI device drivers during the +BS_DEV_RESOURCES state of ramstage. The northcluster driver will +typically specify the DRAM resources while the other drivers will +typically specify the IO resources. These resources are hung off the +struct device *data structure by +src/device/device_util.c/[new_resource](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/device/device...). + +During the BS_WRITE_TABLES state, coreboot collects these resources +and places them into a data structure identified by LB_MEM_TABLE. + +Edit the device driver file: + +1. Implement a read_resources routine which calls macros defined in + src/include/device/[device.h](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/devic...) + like: + - ram_resource + - reserved_ram_resource + - bad_ram_resource + - uma_resource + - mmio_resource + +Testing: Verify that the resources are properly displayed by coreboot +during the BS_WRITE_TABLES state. + +------------------------------------------------------------------------ + +[ACPI Tables]{#AcpiTables} +-------------------------- + +One of the payloads that needs ACPI tables is the EDK2 +[CorebootPayloadPkg](quark.html#CorebootPayloadPkg). + +### FADT + +The EDK2 module +CorebootModulePkg/Library/CbParseLib/[CbParseLib.c](https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/Library/CbPa...) +requires that the FADT contains the values in the table below. These +values are placed into a HOB identified by +[gUefiAcpiBoardInfoGuid](https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/CorebootModu...) +by routine +CorebootModulePkg/CbSupportPei/CbSupportPei/[CbPeiEntryPoint](https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/CbSupportPei...). + + ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- + coreboot Field EDK2 Field gUefiAcpiBoardInfoGuid Use + [ACPI Spec.](http://www.uefi.org/sites/default/files/resources/ACPI_6.0.pdf) Section + + gpe0_blk\ Gpe0Blk\ [PmGpeEnBase](https://github.com/tianocore/edk2/blob/master/CorebootModulePkg/Library/CbPa...) [Shutdown](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) + gpe0_blk_len Gpe0BlkLen + + pm1a_cnt_blk Pm1aCntBlk PmCtrlRegBase [Shutdown](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res... + [Suspend](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) + + pm1a_evt_blk Pm1aEvtBlk PmEvtBase [Shutdown](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) + + pm_tmr_blk PmTmrBlk PmTimerRegBase [Timer](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Acp...) + + reset_reg. ResetReg.Address ResetRegAddress [Cold](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) and + [Warm](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) resets + + reset_value ResetValue ResetValue [Cold](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) and + [Warm](https://github.com/tianocore/edk2/blob/master/CorebootPayloadPkg/Library/Res...) resets + ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------- + +The EDK2 data structure is defined in +MdeModulePkg/Include/IndustryStandard/[Acpi61.h](https://github.com/tianocore/edk2/blob/master/MdePkg/Include/IndustryStandar...) +The coreboot data structure is defined in +src/arch/x86/include/arch/[acpi.h](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/arch/x86/incl...) + +1. Select [HAVE_ACPI_TABLES](../Board/board.html#AcpiTables) in the + board's Kconfig file +2. Create a acpi.c module: + A. Add the acpi_fill_in_fadt routine and initialize the values + above + +------------------------------------------------------------------------ + +[Legacy Hardware]{#LegacyHardware} +---------------------------------- + +One of the payloads that needs legacy hardare is the EDK2 +[CorebootPayloadPkg](quark.html#CorebootPayloadPkg). + + ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- + Peripheral Use 8259 Interrupt Vector IDT Base Offset Interrupt Handler + --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------- ---------------------------------------- ---------------------------------------------------------------------------------------------------------------- + [8254](http://www.scs.stanford.edu/10wi-cs140/pintos/specs/8254.pdf) Programmable Interval Timer EDK2: PcAtChipsetPkg/8254TimerDxe/[Timer.c](https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8254TimerDxe/Ti...) 0 0x340 [TimerInterruptHandler](https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8254TimerDxe/Ti...) + + [8259](https://www.google.com/url?sa=t&rct=j&q=&esrc=s&source=web&a...) Programmable Interrupt Controller EDK2: PcAtChipsetPkg/8259InterruptControllerDxe/[8259.c](https://github.com/tianocore/edk2/blob/master/PcAtChipsetPkg/8259InterruptCo...) Master interrupts: 0, 2 - 7\ Master: 0x340, 0x350 - 0x378\ + Slave interrupts: 8 - 15\ Slave: 0x380 - 0x3b8\ + Interrupt vector 1 is never generated, the cascaded input generates interrupts 8 - 15 Interrupt descriptors are 8 bytes each + ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- + +------------------------------------------------------------------------ + +Modified: 4 March 2016 diff --git a/Documentation/Intel/development.html b/Documentation/Intel/development.html deleted file mode 100644 index 92b1d4b..0000000 --- a/Documentation/Intel/development.html +++ /dev/null @@ -1,377 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>Development</title> - </head> - <body> - -<h1>Intel® x86 coreboot/FSP Development Process</h1> -<p> - The x86 development process for coreboot is broken into the following components: -</p> -<ul> - <li>coreboot <a target="_blank" href="SoC/soc.html">SoC</a> development</li> - <li>coreboot <a target="_blank" href="Board/board.html">mainboard</a> development</li> - <li><a target="_blank" href="fsp1_1.html">FSP 1.1</a> integration</li> -</ul> -<p> - The development process has two main phases: -</p> -<ol> - <li>Minimal coreboot; This phase is single threaded</li> - <li>Adding coreboot features</li> -</ol> - -<h2>Minimal coreboot</h2> -<p> - The combined steps below describe how to bring up a minimal coreboot for a - system-on-a-chip (SoC) and a development board: -</p> -<table> - <tr bgcolor="#ffffc0"> - <td>The initial coreboot steps are single threaded! - The initial minimal FSP development is also single threaded. - Progress can speed up by adding more developers after the minimal coreboot/FSP - implementation reaches the payload. - </td> - </tr> -</table> -<ol> - <li>Get the necessary tools: - <ul> - <li>Linux: Use your package manager to install m4 bison flex and the libcurses development - package. - <ul> - <li>Ubuntu or other Linux distribution that use apt, run: -<pre><code>sudo apt-get install m4 bison flex libncurses5-dev -</code></pre> - </li> - </ul> - </li> - </ul> - </li> - <li>Build the cross tools for i386: - <ul> - <li>Linux: -<pre><code>make crossgcc-i386</code></pre> - To use multiple processors for the toolchain build (which takes a long time), use: -<pre><code>make crossgcc-i386 CPUS=N</code></pre> - where N is the number of cores to use for the build. - </li> - </ul> - </li> - <li>Get something to build: - <ol type="A"> - <li><a target="_blank" href="fsp1_1.html#RequiredFiles">FSP 1.1</a> required files</li> - <li><a target="_blank" href="SoC/soc.html#RequiredFiles">SoC</a> required files</li> - <li><a target="_blank" href="Board/board.html#RequiredFiles">Board</a> required files</li> - </ol> - </li> - <li>Get result to start <a target="_blank" href="SoC/soc.html#Descriptor">booting</a></li> - <li><a target="_blank" href="SoC/soc.html#EarlyDebug">Early Debug</a></li> - <li>Implement and debug the <a target="_blank" href="SoC/soc.html#Bootblock">bootblock</a> code</li> - <li>Implement and debug the call to <a target="_blank" href="SoC/soc.html#TempRamInit">TempRamInit</a></li> - <li>Enable the serial port - <ol type="A"> - <li>Power on, enable and configure GPIOs for the - <a target="_blank" href="Board/board.html#SerialOutput">debug serial UART</a> - </li> - <li>Add the <a target="_blank" href="SoC/soc.html#SerialOutput">serial outupt</a> - support to romstage - </li> - </ol> - </li> - <li>Enable <a target="_blank" href="fsp1_1.html#corebootFspDebugging">coreboot/FSP</a> debugging</li> - <li>Determine the <a target="_blank" href="SoC/soc.html#PreviousSleepState">Previous Sleep State</a></li> - <li>Enable DRAM: - <ol type="A"> - <li>Implement the SoC - <a target="_blank" href="SoC/soc.html#MemoryInit">MemoryInit</a> - Support - </li> - <li>Implement the board support to read the - <a target="_blank" href="Board/board.html#SpdData">Memory Timing Data</a> - </li> - </ol> - </li> - <li>Disable the - <a target="_blank" href="SoC/soc.html#DisableShadowRom">Shadow ROM</a> - </li> - <li>Enable CONFIG_DISPLAY_MTRRS to verify the MTRR configuration</li> - <li> - Implement the .init routine for the - <a target="_blank" href="SoC/soc.html#ChipOperations">chip operations</a> - structure which calls FSP SiliconInit - </li> - <li> - Start ramstage's - <a target="_blank" href="SoC/soc.html#DeviceTree">device tree processing</a> - to display the PCI vendor and device IDs - </li> - <li> - Disable the - <a target="_blank" href="Board/board.html#DisablePciDevices">PCI devices</a> - </li> - <li> - Implement the - <a target="_blank" href="SoC/soc.html#MemoryMap">memory map</a> - </li> - <li>coreboot should now attempt to load the payload</li> -</ol> - - - -<h2>Add coreboot Features</h2> -<p> - Most of the coreboot development gets done in this phase. Implementation tasks in this - phase are easily done in parallel. -</p> -<ul> - <li>Payload and OS Features: - <ul> - <li><a target="_blank" href="SoC/soc.html#AcpiTables">ACPI Tables</a></li> - <li><a target="_blank" href="SoC/soc.html#LegacyHardware">Legacy hardware</a> support</li> - </ul> - </li> -</ul> - - - -<hr> -<table border="1"> - <tr bgcolor="#c0ffc0"> - <th colspan=3><h1>Features</h1></th> - </tr> - <tr bgcolor="#c0ffc0"> - <th>SoC</th> - <th>Where</th> - <th>Testing</th> - </tr> - <tr> - <td>8254 Programmable Interval Timer</td> - <td><a target="_blank" href="SoC/soc.html#LegacyHardware">Legacy hardware</a> support</td> - <td><a target="_blank" href="SoC/quark.html#CorebootPayloadPkg">CorebootPayloadPkg</a> gets to shell prompt</td> - </tr> - <tr> - <td>8259 Programmable Interrupt Controller</td> - <td><a target="_blank" href="SoC/soc.html#LegacyHardware">Legacy hardware</a> support</td> - <td><a target="_blank" href="SoC/quark.html#CorebootPayloadPkg">CorebootPayloadPkg</a> gets to shell prompt</td> - </tr> - <tr> - <td>Cache-as-RAM</td> - <td> - <a target="_blank" href="SoC/soc.html#TempRamInit">Find</a> - FSP binary: - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l38">cache_as_ram.inc</a><br> - Enable: FSP 1.1 <a target="_blank" href="SoC/soc.html#TempRamInit">TempRamInit</a> - called from - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l73">cache_as_ram.inc</a><br> - Disable: FSP 1.1 TempRamExit called from - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l41">after_raminit.S</a><br> - </td> - <td>FindFSP: POST code 0x90 - (<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l205">POST_FSP_TEMP_RAM_INIT</a>) - is displayed<br> - Enable: POST code - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l151">0x2A</a> - is displayed<br> - Disable: CONFIG_DISPLAY_MTRRS=y, MTRRs displayed after call to TempRamExit - </td> - </tr> - <tr> - <td>Memory Map</td> - <td> - Implement a device driver for the - <a target="_blank" href="SoC/soc.html#MemoryMap">north cluster</a> - </td> - <td>coreboot displays the memory map correctly during the BS_WRITE_TABLES state</td> - </tr> - <tr> - <td>MTRRs</td> - <td> - Set values: src/drivers/intel/fsp1_1/stack.c/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/stack.c;hb=HEAD#l42">setup_stack_and_mtrrs</a><br> - Load values: src/drivers/intel/fsp1_1/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l71">after_raminit.S</a> - </td> - <td>Set: Post code 0x91 - (<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l213">POST_FSP_TEMP_RAM_EXIT</a>) - is displayed by - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l41">after_raminit.S</a><br> - Load: Post code 0x3C is displayed by - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l152">after_raminit.S</a><br> - and CONFIG_DISPLAY_MTRRS=y displays the correct memory regions</td> - </tr> - <tr> - <td>PCI Device Support</td> - <td>Implement a PCI <a target="_blank" href="SoC/soc.html#DeviceDrivers">device driver</a></td> - <td>The device is detected by coreboot and usable by the payload</td> - </tr> - <tr> - <td>Ramstage state machine</td> - <td> - Implement the chip and domain operations to start the - <a target="_blank" href="SoC/soc.html#DeviceTree">device tree</a> - processing - </td> - <td> - During the BS_DEV_ENUMERATE state, ramstage now display the device IDs - for the PCI devices on the bus. - </td> - </tr> - <tr> - <td>ROM Shadow<br>0x000E0000 - 0x000FFFFF</td> - <td> - Disable: src/soc/<Vendor>/<Chip Family>/romstage/romstage.c/<a target="_blank" href="SoC/soc.html#DisableShadowRom">soc_after_ram_init routine</a> - </td> - <td>Operates as RAM: Writes followed by a read to the 0x000E0000 - 0x000FFFFF region returns the value written</td> - </tr> - - - <tr bgcolor="#c0ffc0"> - <th>Board</th> - <th>Where</th> - <th>Testing</th> - </tr> - <tr> - <td>Device Tree</td> - <td> - <a target="_blank" href="SoC/soc.html#DeviceTree">List</a> PCI vendor and device IDs by starting - the device tree processing<br> - <a target="_blank" href="Board/board.html#DisablePciDevices">Disable</a> PCI devices<br> - Enable: Implement a PCI <a target="_blank" href="SoC/soc.html#DeviceDrivers">device driver</a> - <td> - List: BS_DEV_ENUMERATE state displays PCI vendor and device IDs<br> - Disable: BS_DEV_ENUMERATE state shows the devices as disabled<br> - Enable: BS_DEV_ENUMERATE state shows the device as on and the device works for the payload - </td> - </tr> - <tr> - <td>DRAM</td> - <td> - Load SPD data: src/soc/mainboard/<Vendor>/<Board>/spd/<a target="_blank" href="Board/board.html#SpdData">spd.c</a><br> - UPD Setup: - <ul> - <li>src/soc<Vendor>//<Chip Family>/romstage/<a target="_blank" href="SoC/soc.html#MemoryInit">romstage.c</a></li> - <li>src/mainboard/<Vendor>/<Board>/<a target="_blank" href="Board/board.html#SpdData">romstage.c</a></li> - </ul> - FSP 1.1 MemoryInit called from src/drivers/intel/fsp1_1/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/raminit.c;hb=HEAD#l126">raminit.c</a> - </td> - <td>Select the following Kconfig values - <ul> - <li>DISPLAY_HOBS</li> - <li>DISPLAY_UPD_DATA</li> - </ul> - Testing successful if: - <ul> - <li>MemoryInit UPD values are correct</li> - <li>MemoryInit returns 0 (success) and</li> - <li>The message "ERROR - coreboot's requirements not met by FSP binary!" - is not displayed - </li> - </ul> - </td> - </tr> - <tr> - <td>Serial Port</td> - <td> - SoC <a target="_blank" href="SoC/soc.html#SerialOutput">Support</a><br> - Enable: src/soc/mainboard/<Board>/com_init.c/<a target="_blank" href="Board/board.html#SerialOutput">car_mainboard_pre_console_init</a> - </td> - <td>Debug serial output works</td> - </tr> - - - <tr bgcolor="#c0ffc0"> - <th>Payload</th> - <th>Where</th> - <th>Testing</th> - </tr> - <tr> - <td>ACPI Tables</td> - <td> - SoC <a target="_blank" href="SoC/soc.html#AcpiTables">Support</a><br> - </td> - <td>Verified by payload or OS</td> - </tr> - - - <tr bgcolor="#c0ffc0"> - <th>FSP</th> - <th>Where</th> - <th>Testing</th> - </tr> - <tr> - <td>TempRamInit</td> - <td>FSP <a target="_blank" href="SoC/soc.html#TempRamInit">TempRamInit</a></td> - <td>FSP binary found: POST code 0x90 - (<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l205">POST_FSP_TEMP_RAM_INIT</a>) - is displayed<br> - TempRamInit successful: POST code - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/cache_as_ram.inc;hb=HEAD#l151">0x2A</a> - is displayed<br> - </td> - </tr> - <tr> - <td>MemoryInit</td> - <td><a target="_blank" href="SoC/soc.html#MemoryInit">SoC</a> support<br> - <a target="_blank" href="Board/board.html#SpdData">Board</a> support<br> - </td> - <td>Select the following Kconfig values - <ul> - <li>DISPLAY_HOBS</li> - <li>DISPLAY_UPD_DATA</li> - </ul> - Testing successful if: - <ul> - <li>MemoryInit UPD values are correct</li> - <li>MemoryInit returns 0 (success) and</li> - <li>The message "ERROR - coreboot's requirements not met by FSP binary!" - is not displayed - </li> - </ul> - </td> - </tr> - <tr> - <td>TempRamExit</td> - <td>src/drivers/intel/fsp1_1/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l51">after_raminit.S</a></td> - <td>Post code 0x91 - (<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/console/post_codes.h;hb=HEAD#l212">POST_FSP_TEMP_RAM_EXIT</a>) - is displayed before calling TempRamExit by - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l141">after_raminit.S</a>, - CONFIG_DISPLAY_MTRRS=y displays the correct memory regions and - Post code 0x39 is displayed by - <a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/after_raminit.S;hb=HEAD#l141">after_raminit.S</a><br> - </td> - </tr> - <tr> - <td>SiliconInit</td> - <td> - Implement the .init routine for the - <a target="_blank" href="SoC/soc.html#ChipOperations">chip operations</a> structure - </td> - <td>During BS_DEV_INIT_CHIPS state, SiliconInit gets called and returns 0x00000000</td> - </tr> - <tr> - <td>FspNotify</td> - <td> - The code which calls FspNotify is located in - src/drivers/intel/fsp1_1/<a target="_blank" href="https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel/fsp1_1/fsp_util.c;hb=HEAD#l182">fsp_util.c</a>. - The fsp_notify_boot_state_callback routine is called three times as specified - by the BOOT_STATE_INIT_ENTRY macros below the routine. - </td> - <td> - The FspNotify routines are called during: - <ul> - <li>BS_DEV_RESOURCES - on exit</li> - <li>BS_PAYLOAD_LOAD - on exit</li> - <li>BS_OS_RESUME - on entry (S3 resume)</li> - </ul> - </td> - </tr> -</table> - - - -<hr> -<p>Modified: 4 March 2016</p> - </body> -</html> diff --git a/Documentation/Intel/development.md b/Documentation/Intel/development.md new file mode 100644 index 0000000..4f34390 --- /dev/null +++ b/Documentation/Intel/development.md @@ -0,0 +1,308 @@ +Intel® x86 coreboot/FSP Development Process +=========================================== + +The x86 development process for coreboot is broken into the following +components: + +- coreboot [SoC](SoC/soc.html) development +- coreboot [mainboard](Board/board.html) development +- [FSP 1.1](fsp1_1.html) integration + +The development process has two main phases: + +1. Minimal coreboot; This phase is single threaded +2. Adding coreboot features + +Minimal coreboot +---------------- + +The combined steps below describe how to bring up a minimal coreboot for +a system-on-a-chip (SoC) and a development board: + + --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- + The initial coreboot steps are single threaded! The initial minimal FSP development is also single threaded. Progress can speed up by adding more developers after the minimal coreboot/FSP implementation reaches the payload. + --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- + +1. Get the necessary tools: + - Linux: Use your package manager to install m4 bison flex and the + libcurses development package. + - Ubuntu or other Linux distribution that use apt, run: + + sudo apt-get install m4 bison flex libncurses5-dev +2. Build the cross tools for i386: + - Linux: + + make crossgcc-i386 + + To use multiple processors for the toolchain build (which takes + a long time), use: + + make crossgcc-i386 CPUS=N + + where N is the number of cores to use for the build. + +3. Get something to build: + A. [FSP 1.1](fsp1_1.html#RequiredFiles) required files + B. [SoC](SoC/soc.html#RequiredFiles) required files + C. [Board](Board/board.html#RequiredFiles) required files +4. Get result to start [booting](SoC/soc.html#Descriptor) +5. [Early Debug](SoC/soc.html#EarlyDebug) +6. Implement and debug the [bootblock](SoC/soc.html#Bootblock) code +7. Implement and debug the call to + [TempRamInit](SoC/soc.html#TempRamInit) +8. Enable the serial port + A. Power on, enable and configure GPIOs for the [debug serial + UART](Board/board.html#SerialOutput) + B. Add the [serial outupt](SoC/soc.html#SerialOutput) support to + romstage +9. Enable [coreboot/FSP](fsp1_1.html#corebootFspDebugging) debugging +10. Determine the [Previous Sleep + State](SoC/soc.html#PreviousSleepState) +11. Enable DRAM: + A. Implement the SoC [MemoryInit](SoC/soc.html#MemoryInit) Support + B. Implement the board support to read the [Memory Timing + Data](Board/board.html#SpdData) +12. Disable the [Shadow ROM](SoC/soc.html#DisableShadowRom) +13. Enable CONFIG_DISPLAY_MTRRS to verify the MTRR configuration +14. Implement the .init routine for the [chip + operations](SoC/soc.html#ChipOperations) structure which calls FSP + SiliconInit +15. Start ramstage's [device tree processing](SoC/soc.html#DeviceTree) + to display the PCI vendor and device IDs +16. Disable the [PCI devices](Board/board.html#DisablePciDevices) +17. Implement the [memory map](SoC/soc.html#MemoryMap) +18. coreboot should now attempt to load the payload + +Add coreboot Features +--------------------- + +Most of the coreboot development gets done in this phase. Implementation +tasks in this phase are easily done in parallel. + +- Payload and OS Features: + - [ACPI Tables](SoC/soc.html#AcpiTables) + - [Legacy hardware](SoC/soc.html#LegacyHardware) support + +------------------------------------------------------------------------ + +Features +======== + +SoC + +Where + +Testing + +8254 Programmable Interval Timer + +[Legacy hardware](SoC/soc.html#LegacyHardware) support + +[CorebootPayloadPkg](SoC/quark.html#CorebootPayloadPkg) gets to shell +prompt + +8259 Programmable Interrupt Controller + +[Legacy hardware](SoC/soc.html#LegacyHardware) support + +[CorebootPayloadPkg](SoC/quark.html#CorebootPayloadPkg) gets to shell +prompt + +Cache-as-RAM + +[Find](SoC/soc.html#TempRamInit) FSP binary: +[cache_as_ram.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... +Enable: FSP 1.1 [TempRamInit](SoC/soc.html#TempRamInit) called from +[cache_as_ram.inc](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... +Disable: FSP 1.1 TempRamExit called from +[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... + +FindFSP: POST code 0x90 +([POST_FSP_TEMP_RAM_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...)) +is displayed\ +Enable: POST code +[0x2A](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) +is displayed\ +Disable: CONFIG_DISPLAY_MTRRS=y, MTRRs displayed after call to +TempRamExit + +Memory Map + +Implement a device driver for the [north +cluster](SoC/soc.html#MemoryMap) + +coreboot displays the memory map correctly during the BS_WRITE_TABLES +state + +MTRRs + +Set values: +src/drivers/intel/fsp1_1/stack.c/[setup_stack_and_mtrrs](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... +Load values: +src/drivers/intel/fsp1_1/[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + +Set: Post code 0x91 +([POST_FSP_TEMP_RAM_EXIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...)) +is displayed by +[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... +Load: Post code 0x3C is displayed by +[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... +and CONFIG_DISPLAY_MTRRS=y displays the correct memory regions + +PCI Device Support + +Implement a PCI [device driver](SoC/soc.html#DeviceDrivers) + +The device is detected by coreboot and usable by the payload + +Ramstage state machine + +Implement the chip and domain operations to start the [device +tree](SoC/soc.html#DeviceTree) processing + +During the BS_DEV_ENUMERATE state, ramstage now display the device IDs +for the PCI devices on the bus. + +ROM Shadow\ +0x000E0000 - 0x000FFFFF + +Disable: src/soc/<Vendor>/<Chip +Family>/romstage/romstage.c/[soc_after_ram_init +routine](SoC/soc.html#DisableShadowRom) + +Operates as RAM: Writes followed by a read to the 0x000E0000 - +0x000FFFFF region returns the value written + +Board + +Where + +Testing + +Device Tree + +[List](SoC/soc.html#DeviceTree) PCI vendor and device IDs by starting +the device tree processing\ +[Disable](Board/board.html#DisablePciDevices) PCI devices\ +Enable: Implement a PCI [device driver](SoC/soc.html#DeviceDrivers) + +List: BS_DEV_ENUMERATE state displays PCI vendor and device IDs\ +Disable: BS_DEV_ENUMERATE state shows the devices as disabled\ +Enable: BS_DEV_ENUMERATE state shows the device as on and the device +works for the payload + +DRAM + +Load SPD data: +src/soc/mainboard/<Vendor>/<Board>/spd/[spd.c](Board/board.html#SpdData)\ +UPD Setup: + +- src/soc<Vendor>//<Chip + Family>/romstage/[romstage.c](SoC/soc.html#MemoryInit) +- src/mainboard/<Vendor>/<Board>/[romstage.c](Board/board.html#SpdData) + +FSP 1.1 MemoryInit called from +src/drivers/intel/fsp1_1/[raminit.c](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + +Select the following Kconfig values + +- DISPLAY_HOBS +- DISPLAY_UPD_DATA + +Testing successful if: + +- MemoryInit UPD values are correct +- MemoryInit returns 0 (success) and +- The message "ERROR - coreboot's requirements not met by FSP binary!" + is not displayed + +Serial Port + +SoC [Support](SoC/soc.html#SerialOutput)\ +Enable: +src/soc/mainboard/<Board>/com_init.c/[car_mainboard_pre_console_init](Board/board.html#SerialOutput) + +Debug serial output works + +Payload + +Where + +Testing + +ACPI Tables + +SoC [Support](SoC/soc.html#AcpiTables)\ + +Verified by payload or OS + +FSP + +Where + +Testing + +TempRamInit + +FSP [TempRamInit](SoC/soc.html#TempRamInit) + +FSP binary found: POST code 0x90 +([POST_FSP_TEMP_RAM_INIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...)) +is displayed\ +TempRamInit successful: POST code +[0x2A](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) +is displayed\ + +MemoryInit + +[SoC](SoC/soc.html#MemoryInit) support\ +[Board](Board/board.html#SpdData) support\ + +Select the following Kconfig values + +- DISPLAY_HOBS +- DISPLAY_UPD_DATA + +Testing successful if: + +- MemoryInit UPD values are correct +- MemoryInit returns 0 (success) and +- The message "ERROR - coreboot's requirements not met by FSP binary!" + is not displayed + +TempRamExit + +src/drivers/intel/fsp1_1/[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...) + +Post code 0x91 +([POST_FSP_TEMP_RAM_EXIT](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/include/conso...)) +is displayed before calling TempRamExit by +[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...), +CONFIG_DISPLAY_MTRRS=y displays the correct memory regions and Post +code 0x39 is displayed by +[after_raminit.S](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel... + +SiliconInit + +Implement the .init routine for the [chip +operations](SoC/soc.html#ChipOperations) structure + +During BS_DEV_INIT_CHIPS state, SiliconInit gets called and returns +0x00000000 + +FspNotify + +The code which calls FspNotify is located in +src/drivers/intel/fsp1_1/[fsp_util.c](https://review.coreboot.org/gitweb?p=coreboot.git;a=blob;f=src/drivers/intel...). +The fsp_notify_boot_state_callback routine is called three times as +specified by the BOOT_STATE_INIT_ENTRY macros below the routine. + +The FspNotify routines are called during: + +- BS_DEV_RESOURCES - on exit +- BS_PAYLOAD_LOAD - on exit +- BS_OS_RESUME - on entry (S3 resume) + +------------------------------------------------------------------------ + +Modified: 4 March 2016 diff --git a/Documentation/Intel/fsp1_1.html b/Documentation/Intel/fsp1_1.html deleted file mode 100644 index 94cb6bf..0000000 --- a/Documentation/Intel/fsp1_1.html +++ /dev/null @@ -1,79 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>FSP 1.1</title> - </head> - <body> - -<h1>FSP 1.1</h1> - -<h2>x86 FSP 1.1 Integration</h2> -<p> - Firmware Support Package (FSP) integration requires System-on-a-Chip (SoC) - and board support. The combined steps are listed - <a target="_blank" href="development.html">here</a>. - The development steps for FSP are listed below: -</p> -<ol> - <li><a href="#RequiredFiles">Required Files</a></li> - <li>Add the <a href="#FspBinary">FSP Binary File</a> to the coreboot File System</li> - <li>Enable <a href="#corebootFspDebugging">coreboot/FSP Debugging</a></li> -</ol> - -<p> - FSP Documentation: -</p> -<ul> - <li>Intel® Firmware Support Package External Architecture Specification <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/technical-specifications/fsp-architecture-spec-v1-1.pdf">V1.1</a></li> -</ul> - -<hr> -<h2><a name="RequiredFiles">Required Files</a></h2> -<h3><a name="corebootRequiredFiles">coreboot Required Files</a></h3> -<ol> - <li>Create the following directories if they do not already exist: - <ul> - <li>src/vendorcode/intel/fsp/fsp1_1/<Chip Family></li> - <li>3rdparty/blobs/mainboard/<Board Vendor>/<Board Name></li> - </ul> - </li> - <li> - The following files may need to be copied from the FSP build or release into the - directories above if they are not present or are out of date: - <ul> - <li>FspUpdVpd.h: src/vendorcode/intel/fsp/fsp1_1/<Chip Family>/FspUpdVpd.h</li> - <li>FSP.bin: 3rdparty/blobs/mainboard/<Board Vendor>/<Board Name>/fsp.bin</li> - </ul> - </li> -</ol> - - -<hr> -<h2><a name="FspBinary">Add the FSP Binary File to coreboot File System</a></h2> -<p> - Add the FSP binary to the coreboot flash image using the following command: -</p> -<pre><code>util/cbfstool/cbfstool build/coreboot.rom add -t fsp -n fsp.bin -b <base address> -f fsp.bin</code></pre> -<p> - This command relocates the FSP binary to the 4K byte aligned location in CBFS so that the - FSP code for TempRamInit may be executed in place. -</p> - - -<hr> -<h2><a name="corebootFspDebugging">Enable coreboot/FSP Debugging</a></h2> -<p> - Set the following Kconfig values: -</p> -<ul> - <li>CONFIG_DISPLAY_FSP_ENTRY_POINTS - Display the FSP entry points in romstage</li> - <li>CONFIG_DISPLAY_HOBS - Display and verify the hand-off-blocks (HOBs) returned by MemoryInit</li> - <li>CONFIG_DISPLAY_VBT - Display Video BIOS Table (VBT) used for GOP</li> - <li>CONFIG_DISPLAY_UPD_DATA - Display the user specified product data passed to MemoryInit and SiliconInit</li> -</ul> - - -<hr> -<p>Modified: 17 May 2016</p> - </body> -</html> diff --git a/Documentation/Intel/fsp1_1.md b/Documentation/Intel/fsp1_1.md new file mode 100644 index 0000000..6be1756 --- /dev/null +++ b/Documentation/Intel/fsp1_1.md @@ -0,0 +1,69 @@ +FSP 1.1 +======= + +x86 FSP 1.1 Integration +----------------------- + +Firmware Support Package (FSP) integration requires System-on-a-Chip +(SoC) and board support. The combined steps are listed +[here](development.html). The development steps for FSP are listed +below: + +1. [Required Files](#RequiredFiles) +2. Add the [FSP Binary File](#FspBinary) to the coreboot File System +3. Enable [coreboot/FSP Debugging](#corebootFspDebugging) + +FSP Documentation: + +- Intel® Firmware Support Package External Architecture Specification + [V1.1](http://www.intel.com/content/dam/www/public/us/en/documents/technical-specif...) + +------------------------------------------------------------------------ + +[Required Files]{#RequiredFiles} +-------------------------------- + +### [coreboot Required Files]{#corebootRequiredFiles} + +1. Create the following directories if they do not already exist: + - src/vendorcode/intel/fsp/fsp1_1/<Chip Family> + - 3rdparty/blobs/mainboard/<Board Vendor>/<Board Name> +2. The following files may need to be copied from the FSP build or + release into the directories above if they are not present or are + out of date: + - FspUpdVpd.h: src/vendorcode/intel/fsp/fsp1_1/<Chip + Family>/FspUpdVpd.h + - FSP.bin: 3rdparty/blobs/mainboard/<Board Vendor>/<Board + Name>/fsp.bin + +------------------------------------------------------------------------ + +[Add the FSP Binary File to coreboot File System]{#FspBinary} +------------------------------------------------------------- + +Add the FSP binary to the coreboot flash image using the following +command: + + util/cbfstool/cbfstool build/coreboot.rom add -t fsp -n fsp.bin -b <base address> -f fsp.bin + +This command relocates the FSP binary to the 4K byte aligned location in +CBFS so that the FSP code for TempRamInit may be executed in place. + +------------------------------------------------------------------------ + +[Enable coreboot/FSP Debugging]{#corebootFspDebugging} +------------------------------------------------------ + +Set the following Kconfig values: + +- CONFIG_DISPLAY_FSP_ENTRY_POINTS - Display the FSP entry points + in romstage +- CONFIG_DISPLAY_HOBS - Display and verify the hand-off-blocks + (HOBs) returned by MemoryInit +- CONFIG_DISPLAY_VBT - Display Video BIOS Table (VBT) used for GOP +- CONFIG_DISPLAY_UPD_DATA - Display the user specified product data + passed to MemoryInit and SiliconInit + +------------------------------------------------------------------------ + +Modified: 17 May 2016 diff --git a/Documentation/Intel/index.html b/Documentation/Intel/index.html deleted file mode 100644 index 9d8aad0..0000000 --- a/Documentation/Intel/index.html +++ /dev/null @@ -1,128 +0,0 @@ -<!DOCTYPE html> -<html> - <head> - <title>Intel® x86</title> - </head> - <body> - -<h1>Intel® x86</h1> - -<h2>Intel® x86 Boards</h2> -<ul> - <li><a target="_blank" href="Board/galileo.html">Galileo</a></li> - <li><a target="_blank" href="http://wiki.minnowboard.org/Coreboot">MinnowBoard MAX</a></li> -</ul> - -<h2>Intel® x86 SoCs</h2> -<ul> - <li><a target="_blank" href="SoC/quark.html">Quark™</a></li> -</ul> - - - -<hr> -<h2>x86 coreboot Development</h2> -<ul> - <li>Get the <a target="_blank" href="https://www.coreboot.org/Git">coreboot source</li> - <li><a target="_blank" href="development.html">Overall</a> development</li> - <li><a target="_blank" href="fsp1_1.html">FSP 1.1</a> integration - </li> - <li><a target="_blank" href="SoC/soc.html">SoC</a> support</li> - <li><a target="_blank" href="Board/board.html">Board</a> support</li> -</ul> - - - -<hr> -<h2>Payload Development</h2> -<ul> - <li><a target="_blank" href="SoC/quark.html#CorebootPayloadPkg">CorebootPayloadPkg</a> - <ul> - <li><a target="_blank" href="https://github.com/tianocore/tianocore.github.io/wiki/EDK-II-Development-Process">EDK II Development Process</a></li> - <li>EDK II <a target="_blank" href="https://github.com/tianocore/tianocore.github.io/wiki/EDK%20II%20White%20papers">White Papers</a></li> - <li><a target="_blank" href="https://github.com/tianocore/tianocore.github.io/wiki/SourceForge-to-Github-Quick-Start">SourceForge to Github Quick Start</a></li> - <li>UEFI <a target="_blank" href="http://www.uefi.org/sites/default/files/resources/UEFI%20Spec%202_5_Errata_A.PDF">2.5 Errata A</a></li> - </ul> - </li> -</ul> - - - -<hr> -<h2><a name="Documentation">Documentation</a></h2> -<ul> - <li>Intel® 64 and IA-32 Architectures <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/manuals/64-ia-32-architectures-software-developer-manual-325462.pdf">Software Developer Manual</a></li> - <li><a target="_blank" href="http://www.uefi.org/specifications">UEFI Specifications</a></li> -</ul> - -<h3><a name="Edk2Documentation">EDK-II Documentation</a></h3> -<ul> - <li>Build <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/Build_Spec_1_26.pdf">V1.26</a></li> - <li>Coding Standards <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/CCS_2_1_Draft.pdf">V2.1</a></li> - <li>DEC <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/DEC_Spec_1_25.pdf">V1.25</a></li> - <li>DSC <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/DSC_Spec_1_26.pdf">V1.26</a></li> - <li><a target="_blank" href="https://github.com/tianocore/tianocore.github.io/wiki/UEFI-Driver-Writer's-Guide">Driver Writer's Guide</a></li> - <li>Expression Syntax <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/ExpressionSyntax_1.1.pdf">V1.1</a></li> - <li>FDF <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/FDF_Spec_1_26.pdf">V1.26</a></li> - <li>INF <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/INF_Spec_1_25.pdf">V1.25</a></li> - <li>PCD <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/PCD_Infrastructure.pdf">PCD</a>V0.55</li> - <li>UNI <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/UNI_File_Spec_v1_2_Errata_A.pdf">V1.2 Errata A</a></li> - <li>VRF <a target="_blank" href="https://github.com/tianocore-docs/Docs/raw/master/Specifications/VFR_1_9.pdf">V1.9</a></li> -</ul> - -<h3><a name="FspDocumentation">FSP Documentation</a></h3> -<ul> - <li>Intel® Firmware Support Package External Architecture Specification <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/technical-specifications/fsp-architecture-spec-v2.pdf">V2.0</a></li> - <li>Intel® Firmware Support Package External Architecture Specification <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/technical-specifications/fsp-architecture-spec-v1-1.pdf">V1.1</a></li> - <li>Intel® Firmware Support Package External Architecture Specification <a target="_blank" href="http://www.intel.com/content/dam/www/public/us/en/documents/technical-specifications/fsp-architecture-spec.pdf">V1.0</a></li> -</ul> - -<h3><a name="FeatureDocumentation">Feature Documentation</a></h3> -<table border="1"> - <tr bgcolor="#c0ffc0"><th>Feature/Specification</th><th>Linux View/Test</th><th>EDK-II View/Test</th></tr> - <tr> - <td><a target="_blank" href="https://en.wikipedia.org/wiki/E820">e820</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man1/dmesg.1.html">dmesg</a></td> - <td> </td> - </tr> - <tr> - <td><a target="_blank" href="http://www.uefi.org/specifications">ACPI</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/precise/man1/acpidump.1.html">acpidump</a></td> - <td> </td> - </tr> - <tr> - <td><a target="_blank" href="https://en.wikipedia.org/wiki/Extended_Display_Identification_Data">EDID</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man1/get-edid.1.html">get-edid | parse-edid</a></td> - <td> </td> - </tr> - <tr> - <td><a target="_blank" href="http://www.nxp.com/documents/user_manual/UM10204.pdf">I2C</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man1/get-edid.1.html">i2cdetect</a></td> - <td> </td> - </tr> - <tr> - <td><a target="_blank" href="http://www.intel.com/design/archives/processors/pro/docs/242016.htm">Multiprocessor</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man1/lscpu.1.html">lscpu</a></td> - <td> </td> - </tr> - <tr> - <td><a target="_blank" href="https://pcisig.com/specifications">PCI</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man8/lspci.8.html">lspci</a></td> - <td><a target="_blank" href="http://www.uefi.org/sites/default/files/resources/UEFI_Shell_Spec_2_0.pdf">pci</a></td> - </tr> - <tr> - <td><a target="_blank" href="https://www.dmtf.org/sites/default/files/standards/documents/DSP0134_3.0.0.pdf">SMBIOS</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/trusty/man8/dmidecode.8.html">dmidecode</a></td> - <td><a target="_blank" href="http://www.uefi.org/sites/default/files/resources/UEFI_Shell_Spec_2_0.pdf">smbiosview</a></td> - </tr> - <tr> - <td><a target="_blank" href="http://www.usb.org/developers/docs/">USB</a></td> - <td><a target="_blank" href="http://manpages.ubuntu.com/manpages/xenial/man8/lsusb.8.html">lsusb</a></td> - <td> </td> - </tr> -</table> - -<hr> -<p>Modified: 18 June 2016</p> - </body> -</html> diff --git a/Documentation/Intel/index.md b/Documentation/Intel/index.md new file mode 100644 index 0000000..5cf10ef --- /dev/null +++ b/Documentation/Intel/index.md @@ -0,0 +1,99 @@ +Intel® x86 +========== + +Intel® x86 Boards +----------------- + +- [Galileo](Board/galileo.html) +- [MinnowBoard MAX](http://wiki.minnowboard.org/Coreboot) + +Intel® x86 SoCs +--------------- + +- [Quark™](SoC/quark.html) + +------------------------------------------------------------------------ + +x86 coreboot Development +------------------------ + +- Get the coreboot source +- [Overall](development.html) development +- [FSP 1.1](fsp1_1.html) integration +- [SoC](SoC/soc.html) support +- [Board](Board/board.html) support + +------------------------------------------------------------------------ + +Payload Development +------------------- + +- [CorebootPayloadPkg](SoC/quark.html#CorebootPayloadPkg) + - [EDK II Development + Process](https://github.com/tianocore/tianocore.github.io/wiki/EDK-II-Development-Pro...) + - EDK II [White + Papers](https://github.com/tianocore/tianocore.github.io/wiki/EDK%20II%20White%20pap...) + - [SourceForge to Github Quick + Start](https://github.com/tianocore/tianocore.github.io/wiki/SourceForge-to-Github-...) + - UEFI [2.5 Errata + A](http://www.uefi.org/sites/default/files/resources/UEFI%20Spec%202_5_Errata_A...) + +------------------------------------------------------------------------ + +[Documentation]{#Documentation} +------------------------------- + +- Intel® 64 and IA-32 Architectures [Software Developer + Manual](http://www.intel.com/content/dam/www/public/us/en/documents/manuals/64-ia-32...) +- [UEFI Specifications](http://www.uefi.org/specifications) + +### [EDK-II Documentation]{#Edk2Documentation} + +- Build + [V1.26](https://github.com/tianocore-docs/Docs/raw/master/Specifications/Build_Spec_...) +- Coding Standards + [V2.1](https://github.com/tianocore-docs/Docs/raw/master/Specifications/CCS_2_1_Dra...) +- DEC + [V1.25](https://github.com/tianocore-docs/Docs/raw/master/Specifications/DEC_Spec_1_...) +- DSC + [V1.26](https://github.com/tianocore-docs/Docs/raw/master/Specifications/DSC_Spec_1_...) +- [Driver Writer's + Guide](https://github.com/tianocore/tianocore.github.io/wiki/UEFI-Driver-Writer%27s...) +- Expression Syntax + [V1.1](https://github.com/tianocore-docs/Docs/raw/master/Specifications/ExpressionS...) +- FDF + [V1.26](https://github.com/tianocore-docs/Docs/raw/master/Specifications/FDF_Spec_1_...) +- INF + [V1.25](https://github.com/tianocore-docs/Docs/raw/master/Specifications/INF_Spec_1_...) +- PCD + [PCD](https://github.com/tianocore-docs/Docs/raw/master/Specifications/PCD_Infrast... +- UNI [V1.2 Errata + A](https://github.com/tianocore-docs/Docs/raw/master/Specifications/UNI_File_Sp...) +- VRF + [V1.9](https://github.com/tianocore-docs/Docs/raw/master/Specifications/VFR_1_9.pdf) + +### [FSP Documentation]{#FspDocumentation} + +- Intel® Firmware Support Package External Architecture Specification + [V2.0](http://www.intel.com/content/dam/www/public/us/en/documents/technical-specif...) +- Intel® Firmware Support Package External Architecture Specification + [V1.1](http://www.intel.com/content/dam/www/public/us/en/documents/technical-specif...) +- Intel® Firmware Support Package External Architecture Specification + [V1.0](http://www.intel.com/content/dam/www/public/us/en/documents/technical-specif...) + +### [Feature Documentation]{#FeatureDocumentation} + + Feature/Specification Linux View/Test EDK-II View/Test + ------------------------------------------------------------------------------------------ ------------------------------------------------------------------------------------------ ----------------------------------------------------------------------------------------- + [e820](https://en.wikipedia.org/wiki/E820) [dmesg](http://manpages.ubuntu.com/manpages/trusty/man1/dmesg.1.html) + [ACPI](http://www.uefi.org/specifications) [acpidump](http://manpages.ubuntu.com/manpages/precise/man1/acpidump.1.html) + [EDID](https://en.wikipedia.org/wiki/Extended_Display_Identification_Data) [get-edid | parse-edid](http://manpages.ubuntu.com/manpages/trusty/man1/get-edid.1.html) + [I2C](http://www.nxp.com/documents/user_manual/UM10204.pdf) [i2cdetect](http://manpages.ubuntu.com/manpages/trusty/man1/get-edid.1.html) + [Multiprocessor](http://www.intel.com/design/archives/processors/pro/docs/242016.htm) [lscpu](http://manpages.ubuntu.com/manpages/trusty/man1/lscpu.1.html) + [PCI](https://pcisig.com/specifications) [lspci](http://manpages.ubuntu.com/manpages/trusty/man8/lspci.8.html) [pci](http://www.uefi.org/sites/default/files/resources/UEFI_Shell_Spec_2_0.pdf) + [SMBIOS](https://www.dmtf.org/sites/default/files/standards/documents/DSP0134_3.0.0.p...) [dmidecode](http://manpages.ubuntu.com/manpages/trusty/man8/dmidecode.8.html) [smbiosview](http://www.uefi.org/sites/default/files/resources/UEFI_Shell_Spec_2_0.pdf) + [USB](http://www.usb.org/developers/docs/) [lsusb](http://manpages.ubuntu.com/manpages/xenial/man8/lsusb.8.html) + +------------------------------------------------------------------------ + +Modified: 18 June 2016
Subrata Banik has posted comments on this change. ( https://review.coreboot.org/c/coreboot/+/32834 )
Change subject: Documentation: Convert Intel to markdown ......................................................................
Patch Set 1: Code-Review+2
Patrick Rudolph has posted comments on this change. ( https://review.coreboot.org/c/coreboot/+/32834 )
Change subject: Documentation: Convert Intel to markdown ......................................................................
Patch Set 1: Code-Review-2
It generates the following warnings:
/home/siro/coreboot/Documentation/Intel/Board/board.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/Board/galileo.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/SoC/quark.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/SoC/soc.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/development.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/fsp1_1.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/index.md: WARNING: document isn't included in any toctree /home/siro/coreboot/Documentation/Intel/Board/board.md:4: WARNING: None:any reference target not found: ../development.html /home/siro/coreboot/Documentation/Intel/Board/galileo.md:4: WARNING: None:any reference target not found: ../SoC/quark.html /home/siro/coreboot/Documentation/Intel/Board/galileo.md:4: WARNING: None:any reference target not found: ../SoC/soc.html /home/siro/coreboot/Documentation/Intel/Board/galileo.md:4: WARNING: None:any reference target not found: ../fsp1_1.html /home/siro/coreboot/Documentation/Intel/Board/galileo.md:4: WARNING: None:any reference target not found: board.html /home/siro/coreboot/Documentation/Intel/Board/galileo.md:35: WARNING: None:any reference target not found: ../SoC/quark.html /home/siro/coreboot/Documentation/Intel/SoC/quark.md:4: WARNING: None:any reference target not found: ../Board/galileo.html /home/siro/coreboot/Documentation/Intel/SoC/quark.md:4: WARNING: None:any reference target not found: soc.html /home/siro/coreboot/Documentation/Intel/SoC/quark.md:4: WARNING: None:any reference target not found: ../fsp1_1.html /home/siro/coreboot/Documentation/Intel/SoC/quark.md:4: WARNING: None:any reference target not found: ../Board/board.html /home/siro/coreboot/Documentation/Intel/SoC/soc.md:4: WARNING: None:any reference target not found: ../development.html /home/siro/coreboot/Documentation/Intel/development.md:7: WARNING: None:any reference target not found: SoC/soc.html /home/siro/coreboot/Documentation/Intel/development.md:8: WARNING: None:any reference target not found: Board/board.html /home/siro/coreboot/Documentation/Intel/development.md:9: WARNING: None:any reference target not found: fsp1_1.html /home/siro/coreboot/Documentation/Intel/fsp1_1.md:7: WARNING: None:any reference target not found: development.html /home/siro/coreboot/Documentation/Intel/index.md:21: WARNING: None:any reference target not found: development.html /home/siro/coreboot/Documentation/Intel/index.md:22: WARNING: None:any reference target not found: fsp1_1.html /home/siro/coreboot/Documentation/Intel/index.md:23: WARNING: None:any reference target not found: SoC/soc.html /home/siro/coreboot/Documentation/Intel/index.md:24: WARNING: None:any reference target not found: Board/board.html
Patrick Rudolph has posted comments on this change. ( https://review.coreboot.org/c/coreboot/+/32834 )
Change subject: Documentation: Convert Intel to markdown ......................................................................
Patch Set 1:
(7 comments)
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/Board/board.md File Documentation/Intel/Board/board.md:
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/Board/board.md@1... PS1, Line 16: [Required Files]{#RequiredFiles} not valid markdown headers
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/Board/board.md@2... PS1, Line 26: A. Selects the SoC for the board and specifies the SPI flash size A. / B. are not threaded as list iterators
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/Board/board.md@2... PS1, Line 27: I. BOARD_ROMSIZE_KB_<Size> no need for _< / >
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/SoC/soc.md File Documentation/Intel/SoC/soc.md:
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/SoC/soc.md@398 PS1, Line 398: static void pci_set_subsystem(struct device *dev, unsigned vendor, unsigned device) use a block for code highlighting: ```c
code
```
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/SoC/soc.md@457 PS1, Line 457: coreboot Field EDK2 Field gUefiAcpiBoardInfoGuid Use seems broken
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/fsp1_1.md File Documentation/Intel/fsp1_1.md:
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/fsp1_1.md@69 PS1, Line 69: Modified: 17 May 2016 can be dropped, sphinx will automatically update this
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/index.md File Documentation/Intel/index.md:
https://review.coreboot.org/#/c/32834/1/Documentation/Intel/index.md@88 PS1, Line 88: [e820](https://en.wikipedia.org/wiki/E820) [dmesg](http://manpages.ubuntu.com/manpages/trusty/man1/dmesg.1.html) whitespace errors
-
